Airtac 3V1 Solenoid Valve 3V1M5B16F
The AirTAC Airtac 3V1 Solenoid Valve 3V1M5B16F is a genuine 3-port 2-position (3/2) solenoid valve with M5 ports. It either feeds its outlet or vents it to exhaust, which is what makes it the valve for single-acting cylinders, on/off air blow, clamping, vacuum switching and pilot duty.
- Valve type3/2-way (3-port, 2-position)
- Port sizeM5
- Coil voltageDC24V
- Electrical entryDIN plug (DIN socket type)
- Stations16
- Series3V1
About the Airtac 3V1 Solenoid Valve 3V1M5B16F
Sixteen independently switched 3/2 valves on one shared base - that is the 3V1M5B16F. Direct-acting, single-solenoid and spring-return, each valve either pressurizes its outlet line or dumps it to exhaust: the right action for spring-return actuators, purge jets and pilot signals. Its M5 ports keep tubing runs and fittings as small as possible.
At DC24V each coil takes 3.0 W, so a fully energized block of sixteen draws roughly 48 W. The IP65 (DIN 40050) enclosure rating protects the coils in dusty or damp corners, and a manual override on every valve speeds up commissioning.
Airtac 3V1 Solenoid Valve 3V1M5B16F Technical Specifications
| Model | Airtac 3V1 Solenoid Valve 3V1M5B16F |
|---|---|
| Series | 3V1 |
| Valve type | 3/2-way (3-port, 2-position) |
| Function | Direct-acting, single solenoid, spring return |
| Port size | M5 |
| Thread | PT |
| Coil voltage | DC24V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | 3.0 W |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
| Vacuum service | Not rated for vacuum |
| Flow coefficient | Not published for 3V1 |
| Temperature | -20 to 70 C |
| Construction | Direct-acting, single solenoid, spring return |
| Protection | IP65 (DIN 40050) |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V1 catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V1 Solenoid Valve 3V1M5B16F
| 3V1 | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| M5 | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| DC24V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| 16F | 16 stations in one assembly. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V1 Solenoid Valve 3V1M5B16F Is Used
Neck blow-off before capping
Sixteen M5 micro-nozzles clear dust and liquid from small-bottle necks on a filling monoblock, one valve per head.
Capsule reject gates on a checkweigher
A bank of sixteen ejector pins nudges out-of-weight capsules off the conveyor as each passes its reject station.
Dispense needles on a potting jig
Single-acting pin cylinders on a connector potting bench dip and release in sequence, driven station by station from one DC24V block.
Is the Airtac 3V1 Solenoid Valve 3V1M5B16F the Right Part?
Because 3V1 has no published Cv, treat it as a low-flow body: for heavier air consumption step up to 3V2 (1/8 or 1/4 port, NC/NO selectable, Cv 0.18-0.19, vacuum rated) or to 3V3 with its 1/4 port and Cv 0.62. If panel space matters more than flow, compare the 3V2M manifold body. Double-acting cylinders are out of scope for any 3/2 valve - route those requirements to the AirTAC 4V range.
Before ordering, confirm the five match points: M5 port, DC24V coil, DIN plug entry, the 16 stations on this assembly, and that your flow demand is genuinely modest - send us the duty flow rates and we will verify.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V1 Solenoid Valve 3V1M5B16F FAQ
Pressure 0-0.8 MPa (0-114 psi), temperature -20 to 70 C, protection IP65 (DIN 40050), and coil power by voltage: 4.5 VA (AC220V and AC110V), 5.0 VA (AC24V), 3.0 W (DC24V, fitted here), 2.5 W (DC12V). The medium is air passing a 40 um or finer filter; lubrication is not required. No Cv is published for the 3V1 series.
All sixteen valves share one manifold, so plumbing collapses to a single supply and one common exhaust instead of sixteen separate valves, brackets and fittings. Wiring stays per valve - each DC24V coil takes its own DIN plug - so your outputs map one-to-one to stations. If one station fails, swap that valve rather than the whole block.
