Airtac 3V1 Solenoid Valve 3V1M5B20F
The AirTAC Airtac 3V1 Solenoid Valve 3V1M5B20F is a genuine 3-port 2-position (3/2) solenoid valve with M5 ports. It either feeds its outlet or vents it to exhaust, which is what makes it the valve for single-acting cylinders, on/off air blow, clamping, vacuum switching and pilot duty.
- Valve type3/2-way (3-port, 2-position)
- Port sizeM5
- Coil voltageDC24V
- Electrical entryDIN plug (DIN socket type)
- Stations20
- Series3V1
About the Airtac 3V1 Solenoid Valve 3V1M5B20F
Twenty stations is the densest block the 3V1 family builds, and the 3V1M5B20F is exactly that: twenty 3/2 valves on a single M5 manifold. Each is direct-acting, single-solenoid and spring-return - it either pressurizes its outlet or vents it to exhaust, suiting spring-return actuators, jets and pilot duties. One supply port, twenty controllable outlets, a fraction of the fittings.
Power stays predictable: 3.0 W per DC24V coil, about 60 W if every station energizes together. IP65 (DIN 40050) protection and a manual override at each position round out the package.
Airtac 3V1 Solenoid Valve 3V1M5B20F Technical Specifications
| Model | Airtac 3V1 Solenoid Valve 3V1M5B20F |
|---|---|
| Series | 3V1 |
| Valve type | 3/2-way (3-port, 2-position) |
| Function | Direct-acting, single solenoid, spring return |
| Port size | M5 |
| Thread | PT |
| Coil voltage | DC24V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | 3.0 W |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
| Vacuum service | Not rated for vacuum |
| Flow coefficient | Not published for 3V1 |
| Temperature | -20 to 70 C |
| Construction | Direct-acting, single solenoid, spring return |
| Protection | IP65 (DIN 40050) |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V1 catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V1 Solenoid Valve 3V1M5B20F
| 3V1 | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| M5 | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| DC24V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| 20F | 20 stations in one assembly. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V1 Solenoid Valve 3V1M5B20F Is Used
Yarn threading jets on a spinning frame
Twenty air-jet nozzles tie on new ends across the spindle bank of a ring-spinning machine, one valve per jet.
Card ejectors on a personalization line
Each station of a card-issuing machine uses a short air puff to push finished cards into the output tray.
Test jets on an EV connector rig
A twenty-way test fixture routes low-pressure air to individual contact cavities to verify seal integrity during end-of-line testing.
Is the Airtac 3V1 Solenoid Valve 3V1M5B20F the Right Part?
At this density, plumbing savings are the headline - but 3V1 remains a small-port, low-flow body with no published Cv, so size up when flow matters: 3V2 (1/8 or 1/4 port, NC/NO selectable, Cv 0.18-0.19, vacuum rated) or 3V3 (1/4 port, Cv 0.62). If you need manifold density with more flow, compare the 3V2M. Double-acting cylinders belong to the 5-port AirTAC 4V family.
Five checks before ordering: M5 port, DC24V coil, DIN plug entry, the 20-station count of this assembly, and your pressure range - the 3V1 covers 0-0.8 MPa. Include duty flow rates in your RFQ and we will verify the fit.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V1 Solenoid Valve 3V1M5B20F FAQ
Operating pressure 0-0.8 MPa (0-114 psi), ambient and media temperature -20 to 70 C, IP65 to DIN 40050. Coil power by voltage: AC220V 4.5 VA, AC110V 4.5 VA, AC24V 5.0 VA, DC24V 3.0 W (fitted here), DC12V 2.5 W. Medium is air filtered to 40 um or finer, no lubrication needed. Cv is not published for the 3V1 - never assume one.
Each valve keeps its own DIN plug connection, so your PLC outputs stay one-to-one with stations and a fault can be isolated valve by valve. Every position has a manual override for setup without power. Pneumatically, one supply feeds the whole base - that is what makes twenty M5 outlets practical on a compact machine.
