Airtac 3V2M Solenoid Valve 3V2MNCA-10F
The AirTAC Airtac 3V2M Solenoid Valve 3V2MNCA-10F is a genuine 3-port 2-position (3/2) solenoid valve with 1/8 in ports. It either feeds its outlet or vents it to exhaust, which is what makes it the valve for single-acting cylinders, on/off air blow, clamping, vacuum switching and pilot duty.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/8 in
- Coil voltageAC220V
- Electrical entryDIN plug (DIN socket type)
- Stations10
- Flow (Cv)0.1
- Series3V2M
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 3V2M Solenoid Valve 3V2MNCA-10F
This 3V2MNCA-10F is a complete assembly: ten normally closed 3/2 valve bodies with AC220V coils and DIN plug entry, matched to a 10-station 3V2M base with a centralised exhaust and PT threads. One air supply feeds the whole block and one wiring run powers all ten coils, so each 7 VA coil hangs off a common circuit instead of ten separate connections.
The centralised exhaust merges all ten station exhausts into a single outlet, which keeps the machine's exhaust plumbing short and lets you duct spent air to one point. Each valve is a direct-acting, spring-return poppet with Cv 0.1 and an IP65 coil. With all ten coils energised the assembly draws roughly 70 VA - size the control transformer for that worst case.
Airtac 3V2M Solenoid Valve 3V2MNCA-10F Technical Specifications
| Model | Airtac 3V2M Solenoid Valve 3V2MNCA-10F |
|---|---|
| Series | 3V2M |
| Valve type | 3/2-way (3-port, 2-position) |
| Function | Direct-acting, single solenoid, spring return |
| Initial state | Normally closed |
| Item form | Complete assembly — 10 valves on a shared base |
| Exhaust | Centralised exhaust |
| Port size | 1/8 in |
| Thread | PT |
| Coil voltage | AC220V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | 7 VA |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
| Vacuum service | Not rated for vacuum |
| Flow coefficient | Cv 0.1 |
| Temperature | -20 to 70 C |
| Construction | Coaxial shut-off (poppet), base-mounted, spring return |
| Protection | IP65 (DIN 40050) |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V2M catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V2M Solenoid Valve 3V2MNCA-10F
| 3V2M | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| AC220V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| 10F | 10 stations in one assembly, centralised exhaust. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V2M Solenoid Valve 3V2MNCA-10F Is Used
Sorter gate array
Drive the diverter gates on a parcel sorting line, with one NC valve per lane fed from the shared manifold supply.
Bottle reject blow-offs
Fire the air jets that push defective bottles off a filling conveyor, all ten exhausts ducted through one common outlet.
Multi-station test bench
Switch the clamps and probe fixtures of a ten-position assembly test rig from a single control cabinet.
Is the Airtac 3V2M Solenoid Valve 3V2MNCA-10F the Right Part?
Check five things before you confirm this assembly: the initial state of every valve (NC here - it cannot be converted after purchase, and reversing the base gasket does not change it), coil voltage (AC220V), entry (DIN plug), thread (PT is standard; G and NPT are catalogue options) and exhaust style (centralised on this code; choose -10FD for independent exhausts).
At Cv 0.1 per station this manifold trades flow for density; step an individual circuit up to a separate 3V2 (Cv 0.18 at 1/8 in, 0.19 at 1/4 in) or 3V3 (Cv 0.62, 1/4 in), both vacuum-rated, where more flow is needed, and use the 3.0 W DC 3V1 for light-duty, low-power duties. A double-acting cylinder needs a 5-port AirTAC 4V valve, not this 3/2 series.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V2M Solenoid Valve 3V2MNCA-10F FAQ
Each station is a 3/2 direct-acting, spring-return poppet valve: Cv 0.1, PT1/8 ports, 0-0.8 MPa (0-114 psi), -20 to 70 C, 7 VA AC coil, IP65. Air must be filtered to 40 um or finer and lubrication is not required. Ten stations share one supply and one centralised exhaust.
This -10F code uses a centralised exhaust: all ten stations vent through one common outlet, which is compact and easy to duct away. If your plant needs each station vented separately - for example to isolate a noisy jet or a dirty exhaust - order the -10FD independent-exhaust version instead. Exhaust type is an order-time choice.
