Airtac 3V2M Solenoid Valve 3V2MNCAI-11F
2、Coaxial shut-off design ensures excellent sealing performance and high flow capacity; Requires no oil lubrication;
3、Equipped with manual override for simplified installation and commissioning;
4、Modular design with base mount enables multi-valve integration for space-saving configurations;
5、Centralized air supply and integrated wiring streamline troubleshooting during fault diagnosis;
6、Flexible and scalable configuration supports arbitrary combinations or expansion of valve quantities/types;
7、Dedicated base gasket design – Flipping the gasket does not allow NC/NO conversion.
Category: Solenoid Valves , Brand: AirTAC , Series: 3V2M
AirTAC 3V2MNCAI-11F Solenoid Valve Technical Details
- Model Code: 3V2MNCAI-11F (Full designation with configuration identifiers)
- Valve Type: 3/2-way normally closed (Pilot-operated with manual override)
- Port Thread: G1/8 (ISO228 standard) with BSPP connection
- Effective Section Area: 12.7mm²
- Operating Pressure Range: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage Variations: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil Insulation: Class F (155℃) with thermal protection
- Response Time: ≤15ms (at rated voltage)
- Flow Capacity: 550 l/min (ANR, at 0.5MPa)
- Seal Material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Ambient Temperature: -5℃ to 60℃ (with condensation prevention)
- Protection Class: IP67 (Dust-tight and temporary immersion protected)
- Weight: 285g ±5g (including coil and connector)
- Dimensions: 53mm(W) × 45mm(H) × 84mm(D) (Excluding ports and fittings)
- Mounting Orientation: Any (Horizontal/vertical with vibration resistance design)
- Service Life: ≥10 million cycles (Under standard operating conditions)
High-flow solenoid valve with dual-position control capability, featuring brass body construction with electroless nickel plating for corrosion resistance. The pilot-operated design enables operation at low differential pressures while maintaining compact dimensions. Integrated surge suppression protects coil from voltage spikes. Requires ISO 8573-1:2010 Class 3.4.3 compressed air (40μm filtration, dew point -25℃).
- CNC machine tool clamping/unclamping sequences
- Textile machinery air cylinder control
- Semiconductor wafer handling robotics
- Food processing pneumatic actuators (FDA-compliant versions available)
- Electric vehicle battery pack cooling systems
Operational Guidelines:
Maintain 85% maximum duty cycle for continuous operation. Use surge voltage absorber (Zener diode) when controlling with PLC outputs. Lubricate spool monthly in high-cycle applications (>500,000 cycles/day).
- Recommended filter regulator: AFR2000F-02D
- Compatible speed controller: ASC300-02
- Mounting base option: VBM-12F series
| Property | Property Value |
|---|---|
| sku | 3V2MNCAI-11F |
| Position | 3-Port 2-Position |
| Initial Position | Normally Closed |
| Standard Voltage | AC220V |
