Airtac 3V300 Solenoid Valve 3V310-08NC-A
2. Spool-type structure ensures excellent sealing performance and responsive operation;
3. Dual-solenoid version features memory function;
4. Precision honing process for inner bore enables reduced friction, low activation pressure, and extended service life;
5. Maintenance-free lubrication system eliminates oil replenishment;
6. Integrated manual override facilitates installation and commissioning;
7. Multiple standard voltage options for flexible integration;
8. Base manifold integration capability enables space-saving configuration.
Category: Solenoid Valves | Brand: Airtac | Series: 3V300
AirTAC 3V310-08NC-A Solenoid Valve Technical Details
- Model: 3V310-08NC-A (3V300 series)
- Valve type: 3/2-way normally closed, direct-acting with manual override
- Port configuration: PT3/8 (G3/8 optional)
- Thread standard: ISO228/1 (BSPP)
- Operating pressure range: 0.15-0.8 MPa (21.7-116 PSI)
- Proof pressure: 1.2 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Flow coefficient (Cv): 2.8 at 0.5 MPa
- Seal material: HNBR (Hydrogenated Nitrile) for improved chemical resistance
- Ambient temperature: -5℃ to 80℃ (with no condensation)
- Vibration resistance: ≤55Hz with 1.5mm amplitude
- Protection class: IP67 (dust-tight and protected against temporary immersion)
- Electrical connection: DIN43650 Form A connector
- Weight: 320g ±5% (excluding packaging)
- Dimensions: 65mm(L) × 40mm(W) × 75mm(H) (port axis to coil face)
High-flow solenoid valve engineered for industrial automation systems requiring rapid cycling. Features corrosion-resistant aluminum alloy body with anodized surface treatment and copper-free construction for food/pharma compatibility. The low-hysteresis design maintains stable operation through 10 million cycles (JIS B8377 tested). Requires 5μm filtered lubricated/non-lubricated air with ISO8573-1:2010 Class 4.4.3 air quality.
- Pneumatic clamping systems in CNC machining centers
- Bottle capping/palletizing machinery
- Electroplating line cylinder controls
- Cleanroom-compatible automation (ISO Class 6 environments)
- Plastic injection molding machine ejectors
Installation guidelines:
Mount in any orientation (horizontal recommended for condensate drainage).
Maintain 15mm clearance from adjacent components. Use M5x0.8 mounting screws
with 0.4-0.6Nm torque. Perform quarterly maintenance checks on seals and filters.
Compatibility note:
Not suitable for vacuum applications or media containing silicone oil.
Use pulse suppression circuit (RC network) when switching >5Hz operation.
| Property | Property Value |
|---|---|
| sku | 3V310-08NC-A |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
