Airtac 3V300 Solenoid Valve 3V31008NC-X0
2. Spool-type structure ensures excellent sealing performance and responsive operation;
3. Dual-solenoid version features memory function;
4. Precision honing process for inner bore enables reduced friction, low activation pressure, and extended service life;
5. Maintenance-free lubrication system eliminates oil replenishment;
6. Integrated manual override facilitates installation and commissioning;
7. Multiple standard voltage options for flexible integration;
8. Base manifold integration capability enables space-saving configuration.
Category: Solenoid Valves | Brand: Airtac | Series: 3V300
AirTAC 3V300 Series Solenoid Valve 3V31008NC-X0 Technical Details
- Model: 3V31008NC-X0 (3V300 platform)
- Valve type: 5/2-way, double solenoid, normally closed
- Port configuration: PT1/4 (G1/8 optional adapter available)
- Operating pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 850 L/min (Cv=1.2 at 0.5MPa)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Weight: 340g ±5% (without connectors)
- Dimensions: 68mm(L) × 38mm(W) × 83mm(H) (body only, exclude fittings)
- Seal materials: HNBR main seals, FKM optional for high-temp
- Temperature tolerance: -5℃ to 80℃ (standard seals), -20℃ to 120℃ (FKM option)
- Coil insulation: Class F (155℃ rated)
- Protection rating: IP67 (coil), IP40 (valve body)
- Service life: ≥10 million cycles (at rated conditions)
High-flow directional control valve featuring dual-coil latching capability and manual override. The hardened aluminum alloy body with anodized treatment resists chemical corrosion in harsh environments. Designed for systems requiring bi-stable position memory and rapid cycling. Requires 5μm filtered lubricated or non-lubricated air (consult manual for lubrication compatibility).
- Automated assembly line clamping/positioning systems
- Plastic injection molding machine ejectors
- Textile machinery pneumatic actuators
- Food processing packaging (FDA-compliant versions available)
- Semiconductor wafer handling robotics
Installation guidelines:
Mount in vibration-free location using M5 mounting holes. Maintain minimum 15mm clearance around exhaust ports.
For dual-coil operation, implement interlock circuit to prevent simultaneous energization.
Lubricate pivot bearings every 2,000 operating hours.
| Property | Property Value |
|---|---|
| sku | 3V31008NC-X0 |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
| Standard Voltage | DC24V |
