Airtac 3V300 Solenoid Valve 3V31008NCC
2. Spool-type structure ensures excellent sealing performance and responsive operation;
3. Dual-solenoid version features memory function;
4. Precision honing process for inner bore enables reduced friction, low activation pressure, and extended service life;
5. Maintenance-free lubrication system eliminates oil replenishment;
6. Integrated manual override facilitates installation and commissioning;
7. Multiple standard voltage options for flexible integration;
8. Base manifold integration capability enables space-saving configuration.
Category: Solenoid Valves | Brand: Airtac | Series: 3V300
AirTAC 3V300 Series Solenoid Valve 3V31008NCC Technical Specifications
- Model: 3V31008NCC
- Valve type: 3-position, 5-way (3V300 series)
- Operation mode: Double solenoid with spring return
- Port size: PT1/4 (G1/4 optional)
- Thread standard: ISO G/PT/NPT available
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Max flow rate: 750 L/min (ANR)
- Voltage options: DC12V, DC24V, AC110V(50/60Hz), AC220V(50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: HNBR (Hydrogenated Nitrile) for high temp resistance
- Temperature range: -5℃ to 80℃ (no icing)
- Ambient humidity: 35–95% RH
- Protection rating: IP67 (dustproof/water immersion resistant)
- Weight: 320g ±5% (excluding accessories)
- Dimensions: 54mm(W) × 45mm(H) × 126mm(L)
- Mounting: ISO 5599-1 standard sub-base compatible
- Cycle life: ≥10 million operations
High-flow 5/3-way solenoid valve engineered for complex pneumatic circuits requiring mid-position control. Features brass body with electroless nickel plating for corrosion resistance and zero-lash spool design for vibration resistance. Includes manual override and surge suppression circuitry. Requires 5μm filtered compressed air with oil mist lubrication (ISO 8573-1 Class 3).
- Clamping sequence control in injection molding machines
- Automated production line transfer systems
- Robotic arm end-effector tool switching
- Pressurized tank venting systems
- Automotive brake testing equipment
- Food packaging machine safety interlocks
Installation guidelines:
Mount horizontally with coil facing upward. Use flexible tubing for vibration isolation.
Maintain minimum 20mm clearance around valve body for heat dissipation.
For continuous operation, install auxiliary cooling when ambient temperature exceeds 50℃.
Critical note:
Do NOT use with oxidizing gases. Maximum allowable pressure differential:
0.8MPa when switching. Always install downstream pressure regulator
for vacuum applications.
| Property | Property Value |
|---|---|
| sku | 3V31008NCC |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
| Standard Voltage | AC 110V |
