Airtac 3V300 Solenoid Valve 3V31008NOA-AM
2. Spool-type structure ensures excellent sealing performance and responsive operation;
3. Dual-solenoid version features memory function;
4. Precision honing process for inner bore enables reduced friction, low activation pressure, and extended service life;
5. Maintenance-free lubrication system eliminates oil replenishment;
6. Integrated manual override facilitates installation and commissioning;
7. Multiple standard voltage options for flexible integration;
8. Base manifold integration capability enables space-saving configuration.
Category: Solenoid Valves | Brand: Airtac | Series: 3V300
AirTAC 3V300 Series Solenoid Valve 3V31008NOA-AM Technical Details
- Full model designation: 3V31008NOA-AM (3V300 platform)
- Valve type: 3-position 5-way closed center (3V3 series)
- Operation mode: Double solenoid pilot-operated
- Port configuration: G1/8 (ISO228-1) with optional NPT1/8
- Pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤50ms (energize), ≤30ms (de-energize)
- Flow capacity: 850 l/min (Cv=1.2) at 0.5MPa
- Seal materials: HNBR main seals with FKM backup rings
- Ambient temperature: -10℃ to 60℃ (non-freezing)
- Power consumption: 2.8W (DC), 4.5VA (AC)
- Protection grade: IP67 (coil), IP40 (valve body)
- Weight: 480g ±5% (with mounting bracket)
- Dimensions: 58mm (L) × 34mm (W) × 74mm (H)
High-flow proportional control valve with center exhaust configuration, featuring anti-vibration coil design and surge protection circuitry. The anodized aluminum body incorporates a manual override button for system debugging. Requires ISO 8573-1:2010 Class 3.4.2 compressed air (max 50μm particles, -20℃ dew point).
- Multi-position cylinder control in assembly line automation
- Pneumatic clamping systems for CNC machining centers
- Material handling equipment with position hold requirements
- Textile machinery with bidirectional actuator control
- Battery production line vacuum/pressure switching
Installation guidelines:
Mount horizontally with ports downward to prevent debris accumulation.
Use M4×12 stainless steel screws (1.2-1.5Nm torque). Maintain ≥15mm
clearance from heat sources. Lubricate with ISO VG32 turbine oil if
operating below -5℃.
| Property | Property Value |
|---|---|
| sku | 3V31008NOA-AM |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
