Airtac 3V300 Solenoid Valve 3V320-10-A
2. Spool-type structure ensures excellent sealing performance and responsive operation;
3. Dual-solenoid version features memory function;
4. Precision honing process for inner bore enables reduced friction, low activation pressure, and extended service life;
5. Maintenance-free lubrication system eliminates oil replenishment;
6. Integrated manual override facilitates installation and commissioning;
7. Multiple standard voltage options for flexible integration;
8. Base manifold integration capability enables space-saving configuration.
Category: Solenoid Valves | Brand: Airtac | Series: 3V300
AirTAC 3V320-10-A Solenoid Valve Technical Specifications
- Model: 3V320-10-A (3V300 Series)
- Valve type: 5/2-way, double solenoid (closed-center configuration)
- Port size: G1/8 (ISO228/1 standard)
- Thread type: Internal parallel (BSPP)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Max flow rate: 750 l/min (Cv=1.2)
- Voltage options: DC12V(±10%), DC24V(±10%), AC110V(50/60Hz), AC220V(50/60Hz)
- Coil insulation class: Class F (155℃)
- Duty cycle: Continuous operation capable
- Response time: ≤30ms (at rated voltage)
- Seal material: HNBR (Hydrogenated Nitrile) for high temp resistance
- Temperature range: -10℃ to 80℃ (with 0.1-0.8 MPa)
- Power consumption: 2.8W (DC), 4.5VA (AC)
- Protection rating: IP67 (dustproof & temporary immersion)
- Weight: 250g ±5% (including coil)
- Dimensions: 70mm(L) × 45mm(W) × 80mm(H)
- Port positions: 5 ports (P:1, A:2, B:4, EA:3, EB:5)
High-flow proportional control valve with dual-coil latching capability, featuring gold-plated terminals for corrosion prevention. The 3V320-10-A's zero-leakage spool design ensures precise cylinder control in bi-directional applications. Requires 5μm filtered lubricated air (ISO 8573-1 class 4). Compatible with ISO 5599/1 mounting interfaces.
- Automatic production line indexing systems
- Hydraulic system pilot stage control
- Plastic injection molding machine clamps
- Automotive brake testing equipment
- Bottle filling/palletizing systems
- CNC machine tool clamping sequences
Installation guidelines:
Maintain ≤3° deviation from horizontal mounting plane.
Use M5x8 mounting screws with 0.4-0.6Nm torque.
Allow 15mm clearance below valve for manifold heat dissipation.
Perform monthly manual override tests for maintenance.
| Property | Property Value |
|---|---|
| sku | 3V320-10-A |
| Position | 3-Port 2-Position |
| Port Size | PT3/8 |
| Standard Voltage | AC220V |
