Airtac 400M Solenoid Valve Manifold Base 400M10F
AirTAC 400M10F Manifold Base Specifications
- Model: 400M10F (Modular Multi-Station Base)
- Type: ISO 5599/1 Standard Sub-Base for Multiple Solenoid Valves
- Port size: G1/8 (NPT1/8 optional)
- Number of stations: 10 positions
- Material: Aluminum alloy ADC12 with hard anodized finish
- Seal material: NBR/FKM (standard/viton option)
- Operating pressure: 0.1–1.0 MPa
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Mounting style: DIN rail or direct screw mounting
- Weight: 580g ±2%
- Dimensions: 220mm(L) × 48mm(W) × 82mm(H)
- Port alignment: 20mm center-to-center spacing
- Flow capacity: 650 l/min (at 0.5 MPa)
- Compatible valves: 4000/5000/6000 series solenoid valves
High-density modular base designed for centralized pneumatic control systems, featuring leak-proof design with embedded O-ring grooves and precision-machined flow channels. The T-slot construction allows flexible valve combinations and easy maintenance. Includes integrated pressure gauge ports and optional end plates (sold separately).
- Automated assembly line control panels
- Textile machinery multi-cylinder sequencing
- Plastic injection molding machine clusters
- Semiconductor wafer handling systems
- Beverage filling plant manifold systems
Installation note:
Apply silicone-free lubricant to O-rings before assembly. Use torque-limited wrench
(1.5-2.0 Nm) for valve mounting. Install drip-proof cover (400MC series) in humid environments.
| Property | Property Value |
|---|---|
| sku | 400M10F |
