Airtac 400M Solenoid Valve Manifold Base 400M16F
AirTAC 400M Series Manifold Base 400M16F Technical Specifications
- Model: 400M16F (Sub-base for 400M valve series)
- Type: Modular manifold base for multi-valve assembly
- Port size: G1/8 (BSPP thread standard)
- Material: Aluminum alloy ADC12 with anodized surface
- Compatible valves: 400M series solenoid valves (4V, 5V, 6V port types)
- Mounting style: DIN rail TS35 or direct panel mounting
- Max operating pressure: 1.0 MPa (145 psi)
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Weight: 280g ±5g (excluding valves)
- Dimensions: 80mm(L) × 42mm(W) × 22mm(H) per station
- Seal material: Nitrile rubber (NBR) standard, optional Viton(FKM)
- Surface roughness: Ra ≤3.2μm for sealing surfaces
- Installation torque: 1.2-1.5 N·m for port connections
- Protection rating: IP40 (base only, varies with valve assembly)
The 400M16F modular manifold enables centralized control of multiple pneumatic circuits through stacked valve installation. Its precision-machined flow channels minimize pressure drop (ΔP ≤0.02MPa @ 0.5MPa) while the staggered port design allows 360° orientation flexibility. Features integrated silencer mounts and optional end plates for system expansion.
- Multi-axis pneumatic control systems requiring synchronized actuation
- Automated assembly lines with space-constrained valve clusters
- Modular packaging machinery with quick-change valve configurations
- PLC-controlled industrial robots using ISO 15407-1 compliant components
- Laboratory equipment requiring vibration-resistant pneumatic connections
Installation protocol:
Apply thread sealant (LOCTITE 545) on port connections.
Maintain 0.5mm minimum clearance between manifold stacks for thermal expansion.
Use torque wrench for even pressure distribution across mounting screws.
| Property | Property Value |
|---|---|
| sku | 400M16F |
