Airtac 400M Solenoid Valve Manifold Base 400M9F
AirTAC 400M9F Valve Manifold Base Technical Specifications
- Model: 400M9F (ISO 15407-1 compliant)
- Type: Modular valve base for multiple valve assembly
- Compatible Valve Series: 400M series solenoid valves
- Port Configuration: 9 ports (3 inlets, 6 outlets)
- Port Thread: G1/8 (BSPP) with ISO standardization
- Material: Anodized aluminum alloy (AL6063-T5)
- Pressure Range: 0.1-1.0 MPa (14.5-145 PSI)
- Temperature Range: -20℃ to 80℃ (operating fluid)
- Surface Hardness: HV 120±15 (anodized layer)
- Weight: 320g ±5% (without attached valves)
- Dimensions: 89mm(L) × 35mm(W) × 52mm(H)
- Seal Material: NBR (Nitrile Butadiene Rubber)
- Mounting: DIN rail compatible (35mm width)
- Leakage Rate: ≤3 bubbles/min (under 0.5 MPa)
- Protection Rating: IP40 (terminal area)
Precision-engineered modular base for creating multi-valve pneumatic control systems. Features cross-ported internal channels for simplified piping, with color-coded port indicators (red: supply, blue: exhaust, black: output). The staggered O-ring design ensures zero-interference sealing when stacking multiple units.
- Centralized control systems for CNC tool changers
- Multi-axis pneumatic actuator synchronization
- Automated assembly line clamping stations
- Plastic injection molding machine air circuits
- Textile machinery pneumatic clusters
Installation Protocol:
Apply 3-5Nm torque during screw tightening. Use M4x12mm stainless steel screws
for valve mounting. Always perform pneumatic circuit purging (3-5 cycles at 0.3MPa)
before full-pressure operation.
| Property | Property Value |
|---|---|
| sku | 400M9F |
