Airtac 4A100 Pneumatic Control Valve 4A120M5
2. Three-position pneumatic valve offers three selectable mid-position functions;
3. Dual-head 2-position configuration features memory retention capability;
4. Specialized machining processes for internal bores achieve low frictional resistance, low activation pressure, and extended service life;
5. Oil-free lubrication required;
6. Compatible with manifold base integration for space-efficient installation;
Category: Pneumatic Control Valves | Brand: AirTAC | Series: 4A100
AirTAC 4A100 Series 4A120M5 Pneumatic Control Valve Specifications
- Model: 4A120M5 (4A100 series)
- Valve type: 5-port 3-position closed center (Pneumatic pilot operated)
- Port size: G1/8 (ISO228 standard) with M5 sub-port option
- Operating pressure range: 0.2–1.0 MPa (29–145 PSI)
- Max flow capacity: 750 L/min (ANR) at 0.5 MPa
- Voltage compatibility: DC12V/24V (±10%), AC110V/220V (50/60Hz)
- Weight: 480g ±2% (including connectors)
- Dimensions: 54mm(W) × 50mm(H) × 135mm(L)
- Seal materials: HNBR main seals with FKM backup rings
- Temperature tolerance: -10℃ to 80℃ (non-freezing environment)
- Response time: ≤0.1s (at rated voltage)
- Durability: 10 million cycles minimum
- Port thread depth: 10mm (minimum engagement)
- Protection class: IP67 (dust/water resistant)
High-flow modular pneumatic directional valve featuring metal-body construction with corrosion-resistant aluminum alloy. The dual-pilot operated design ensures stable switching under vibration conditions. Integrated surge suppression protects against voltage spikes. Requires 5μm filtered lubricated air (ISO8573-1 class 4) with 20-50 cSt oil viscosity.
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changers and spindle brakes
- Foundry equipment cylinder control
- High-cycle packaging machinery
Installation guidelines:
Mount on ISO 5599/1 compliant manifold base. Maintain ambient temperature
below 60℃ with 30mm clearance for heat dissipation. Use thread sealant
(Loctite 5452 recommended) for port connections. Perform monthly manual
override testing for maintenance.
| Property | Property Value |
|---|---|
| sku | 4A120M5 |
| Position | 5 Ports 2 Position |
| Port Size | M5 |
