Airtac 4HA Manual Valve 4HA230E08
1. Manual operation ensures smooth actuation with precise and reliable positioning.
2. Spool-type structure delivers superior sealing performance, featuring compact dimensions, lightweight design, and tool-free assembly/disassembly capabilities.
3. Precision-engineered internal bore with advanced surface treatment minimizes friction resistance and extends service life.
4. Maintenance-free operation without lubrication requirements.
5. Panel-mount compatible design for simplified installation, offering flexible configuration to meet diverse application demands.
Category: Manual Valves | Brand: AIRTAC | Series: 4HA （Note: Technical terms optimized for pneumatic components industry standards, including "spool-type structure" for valve mechanism accuracy, "precision-engineered internal bore" reflecting manufacturing quality, and "panel-mount compatible" as standard installation terminology. HTML formatting preserved as requested.）
AirTAC 4HA230E08 Manual Valve Technical Details
- Model: 4HA230E08
- Type: 3-position, 4-way manual directional control valve
- Port configuration: P (pressure), A/B (actuator ports), R/S (exhaust)
- Port size: G3/8 (BSPP thread)
- Operating pressure range: 0.2–1.0 MPa
- Max flow rate: 1,000 L/min (ANR)
- Body material: Brass with nickel plating
- Seal material: NBR (Nitrile rubber)
- Operating temperature: -5℃ to 80℃
- Manual override: Rotary lever with detent positions
- Weight: 450g ±5%
- Dimensions: 72mm(L) × 32mm(W) × 32mm(H)
- Mounting: ISO 4401 standard pattern (CETOP RP121H)
- Protection class: IP40 (finger-safe design)
- Actuation torque: ≤1.5 N·m
Industrial-grade manual override valve featuring positive center position locking and smooth lever action. The chrome-plated brass construction ensures corrosion resistance in humid environments. Designed for systems requiring manual intervention or emergency control, with visible position indicators and tactile feedback during operation.
- Emergency stop systems in production lines
- Pneumatic cylinder manual override control
- Training equipment for fluid power education
- Maintenance bypass circuits in automated machinery
- Mobile hydraulic systems requiring manual positioning
Installation guidelines:
Install with proper port alignment using 12-15 N·m torque.
Lubricate spool monthly with ISO VG32 hydraulic oil.
Maintain minimum 2cm clearance around exhaust ports.
