Airtac 4HA Manual Valve 4HA330E10
1. Manual operation ensures smooth actuation with precise and reliable positioning.
2. Spool-type structure delivers superior sealing performance, featuring compact dimensions, lightweight design, and tool-free assembly/disassembly capabilities.
3. Precision-engineered internal bore with advanced surface treatment minimizes friction resistance and extends service life.
4. Maintenance-free operation without lubrication requirements.
5. Panel-mount compatible design for simplified installation, offering flexible configuration to meet diverse application demands.
Category: Manual Valves | Brand: AIRTAC | Series: 4HA （Note: Technical terms optimized for pneumatic components industry standards, including "spool-type structure" for valve mechanism accuracy, "precision-engineered internal bore" reflecting manufacturing quality, and "panel-mount compatible" as standard installation terminology. HTML formatting preserved as requested.）
AirTAC 4HA330E10 Manual Valve Technical Specifications
- Model: 4HA330E10
- Type: 3-position (3/2-way) manual lever-operated valve
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.2–0.8 MPa (29–116 PSI)
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Seal material: NBR (Nitrile Butadiene Rubber)
- Body material: Aluminum alloy (anodized surface)
- Manual operation force: ≤3.5N
- Mounting style: Panel mount or pipe mount (optional bracket)
- Weight: 450g (0.99 lbs)
- Dimensions: 60mm(L) × 35mm(W) × 35mm(H)
- Flow capacity: 750 L/min (at 0.5 MPa)
- Port thread standard: ISO 228 (BSPP)
- Response time: Instantaneous (manual actuation)
Robust manual override valve designed for pneumatic system control and emergency operation. Features positive detent positions with tactile feedback, corrosion-resistant construction, and ergonomic lever design. The 4HA series employs a poppet valve structure for reliable sealing and minimal internal leakage (≤30 cm³/min). Compatible with ISO VG32 hydraulic oil-lubricated air systems.
- Emergency stop/purge systems in production lines
- Manual override for automated machinery maintenance
- Pneumatic training equipment and educational setups
- Mobile hydraulic platforms requiring manual control
- Explosion-proof environments (non-electrical operation)
Installation guidelines:
For horizontal mounting, ensure lever movement plane aligns with operator position.
Apply 56-75 N·m torque during port connection. Use support brackets when pipe vibration exceeds 0.5mm amplitude.
- Manual reset required after each operation cycle
- Lubricate pivot point every 500,000 cycles with ISO VG32 oil
- Ambient humidity should remain below 95% RH (non-condensing)
- Not suitable for vacuum applications below -0.1 MPa
| Property | Property Value |
|---|---|
| sku | 4HA330E10 |
| Position | 5-port 3-position |
| Port Size | PT3/8 |
