Airtac 4M Solenoid Valve 4M11006AI
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M11006AI Solenoid Valve Specifications
- Model: 4M11006AI
- Type: 4-way, 5-port (3-position closed center)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–0.8 MPa (29–116 psi)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 480g ±2% (including coil)
- Dimensions: 54mm(L) × 40mm(W) × 80mm(H)
- Body material: Die-cast aluminum alloy with hard anodizing
- Seal material: Heat-resistant NBR (Nitrile) / Optional FKM (Fluorocarbon)
- Temperature range: -5℃ to 80℃ (with NBR), -10℃ to 150℃ (with FKM)
- Flow capacity: 1200 NL/min (Cv=1.8)
- Response time: ≤25ms (energize), ≤15ms (de-energize)
- Protection rating: IP67 (coil), IP40 (valve body)
- Mounting type: ISO 15407-1 compliant sub-base mounting
High-flow directional control valve with closed-center configuration, featuring triple electromagnetic shielding and surge protection circuitry. Designed for precision mid-pressure pneumatic systems requiring stable neutral position. The dual-color LED status indicator (red/green) enables quick operational diagnostics. Requires 5μm filtered lubricated air (ISO 8573-1 class 4) with 20-50 cSt oil viscosity.
- Plastic injection molding machine clamp control
- Automated assembly line positioning systems
- Textile machinery cylinder sequencing
- Semiconductor wafer handling equipment
- Hydraulic system pilot stage control
Installation guidelines:
Maintain horizontal mounting orientation (±15° tolerance). Use copper-free anti-vibration washers.
For continuous operation, implement 15-minute duty cycle breaks every 6 hours. Lubrication interval:
5 million cycles or 6 months (whichever comes first).
| Property | Property Value |
|---|---|
| sku | 4M11006AI |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | AC220V |
