Airtac 4M Solenoid Valve 4M11006BI
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M11006BI Solenoid Valve Technical Specifications
- Model: 4M11006BI
- Valve type: 5/2-way single solenoid control (monostable)
- Port configuration: 1/4" BSPP (G1/4)
- Operating pressure range: 0.1–1.0 MPa
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC24V: 2.5W max | AC: 4.5VA max
- Response time: ≤15ms (at 0.5MPa)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Ambient temperature: -5℃ to 60℃ (with no freezing)
- Fluid temperature: 0–60℃
- Effective flow rate: 750 l/min (ANR)
- Protection class: IP67 (dust tight and protected against temporary immersion)
- Weight: 220g ±5g
- Dimensions: 50mm (L) × 25mm (W) × 72mm (H)
- Port thread depth: 12mm (full thread engagement recommended)
High-flow directional control valve with industrial-grade durability, featuring copper-free aluminum alloy body and self-lubricating seals. Designed for rapid cycling applications requiring precise directional changes. Includes manual override button for system debugging. Requires 5μm filtration (40μm for temporary use).
- Pneumatic cylinder sequencing in assembly lines
- Clamping mechanisms in CNC machining centers
- Material handling systems with rapid cycling demands
- Plastic injection molding machine actuators
- Automated test equipment requiring IP67 protection
Installation guidelines:
Mount with vibration-resistant brackets in environments exceeding 0.5G vibration.
Maintain minimum 15mm clearance on exhaust ports. Lubricate with ISO VG32
turbine oil if operating below -5℃. Replace seals every 5 million cycles
under continuous operation.
| Property | Property Value |
|---|---|
| sku | 4M11006BI |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
