Airtac 4M Solenoid Valve 4M12006B
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M12006B 5/2-Way Solenoid Valve Technical Details
- Model: 4M12006B (2-position 5-way)
- Operation type: Double solenoid pilot-operated
- Port configuration: G1/8 (ISO228/1 standard)
- Effective area ratio: 1:1.15 (pilot piston design)
- Operating pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC12V(±10%), DC24V(±10%), AC110V(±15%), AC220V(±15%)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Max flow rate: 850 l/min (ANR, at 0.5 MPa)
- Response time: ≤30ms (exhaust to actuation)
- Ambient temperature: -5℃ to 60℃ (with anti-condensation heater optional)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Body material: Die-cast aluminum with epoxy coating
- Protection class: IP67 (dustproof & temporary immersion)
- Weight: 310g ±5% (excluding connectors)
- Dimensions: 58mm(L) × 34mm(W) × 74mm(H) (manual override protrusion included)
- Port thread depth: 10mm (minimum engagement requirement)
High-flow directional control valve featuring dual coil redundancy and manual override capability. The hardened stainless steel pilot mechanism ensures 1,000,000+ cycle durability. Optimized flow paths reduce pressure drop by 18% compared to previous generation models. Requires ISO 8573-1 class 3 compressed air (max 5mg/m³ oil content).
- Clamping sequence control in CNC machining centers
- Pneumatic cylinder reversing in automotive assembly robots
- Vacuum cup array switching for glass handling systems
- Mold core pulling mechanisms in injection molding
- Batching system diverter valves for bulk material handling
Installation protocol:
Mount with M4 screws (4.8N·m torque limit). Maintain 20mm clearance
below valve for exhaust dispersion. Lubricate seals with ISO VG32
turbine oil if operated below -5℃. Perform monthly pilot filter inspection
in high particulate environments.
- Class F insulation (155℃ thermal rating)
- 100% ED (continuous duty cycle)
- Coil rotation: 360° adjustable (22.5° increment locking)
- Surge protection: Built-in varistor (DC models)
| Property | Property Value |
|---|---|
| sku | 4M12006B |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
