Airtac 4M Solenoid Valve 4M21006-X0
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M21006-X0 Solenoid Valve Specifications
- Model: 4M21006-X0
- Type: 5/2-way pilot-operated (double solenoid)
- Port size: PT1/4 (NPT1/4 optional)
- Operating pressure: 0.15–0.85 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10% tolerance)
- Weight: 350g ±5% (including coil)
- Dimensions: 60mm(L) × 35mm(W) × 90mm(H)
- Flow capacity: 1200 NL/min (ANR at 0.5 MPa)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Power consumption: ≤2.5W (DC), ≤3.5VA (AC)
- Port thread depth: 10mm (full thread engagement recommended)
- Response time: ≤20ms (at rated voltage)
- Protection rating: IP67 (coil), IP40 (valve body)
- Electrical connection: DIN43650 Form A (standard)
- Cycle life: ≥10 million operations (under rated conditions)
High-flow 5/2-way solenoid valve with dual manual override and LED status indicator. Features aluminum alloy body with hard anodized finish for corrosion resistance in humid environments. Designed for bi-directional control in automation systems requiring precise directional switching. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.3 quality.
- Pneumatic cylinder sequencing in packaging lines
- Rotary actuator control for material handling robots
- Clamping/unclamping operations in CNC fixtures
- Air blow systems for plastic injection molding
- Textile machinery tension control mechanisms
Installation guidelines:
Mount horizontally with coil upright. Use anti-vibration pads in high-frequency applications (>15Hz).
Allow 30mm clearance for manual override access. Lubricate with ISO VG32 turbine oil if air line lubrication isn't present.
Critical note:
Do NOT use silicone-based lubricants. Ensure exhaust ports are piped away from sensitive components -
exhaust flow velocity reaches 25 m/s at 0.5 MPa. Compatible with ISO 6358 testing standards.
| Property | Property Value |
|---|---|
| sku | 4M21006-X0 |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
