Airtac 4M Solenoid Valve 4M21008-A
$25.55
Regular price
$33.05
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
4M21008-A
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Internal pilot-operated design;
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
Installation guidelines:
Mount in vibration-free locations using M5 mounting screws (max torque 1.2N·m).
Maintain 20mm minimum clearance around exhaust ports. Lubricate with ISO VG32
turbine oil if using non-lubricated air systems. Replace seals every 5 million
cycles under normal operation.
Critical note:
Requires 5μm filtration (40μm for emergency use only). Never apply pressure
during electrical connection/disconnection. Allow 2-minute cooldown between
continuous duty cycles exceeding 30 minutes.
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M210-08-A Solenoid Valve Technical Specifications
- Model: 4M210-08-A (4M21008-A)
- Valve type: 5-port 2-position (5/2-way) pilot-operated
- Port thread: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Flow capacity: CV 0.48 (Kv 0.42)
- Seal material: Heat-resistant NBR (-5℃ to 80℃)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Weight: 320g ±5% (excluding accessories)
- Dimensions: 80mm(L) × 50mm(W) × 62mm(H)
- Protection class: IP65 (coil section)
- Porting pattern: ISO 5599-1 standard
High-flow directional control valve with double electrical control and pneumatic reset function. Features aluminum alloy body with hard anodized treatment for enhanced wear resistance. Designed for systems requiring bi-directional cylinder control with maintained position memory.
Industrial Applications:
- Pneumatic clamping systems in CNC machinery
- Automatic production line transfer units
- Plastic injection molding machine actuators
- Material handling equipment with double-acting cylinders
- Automated assembly station positioning systems
Installation guidelines:
Mount in vibration-free locations using M5 mounting screws (max torque 1.2N·m).
Maintain 20mm minimum clearance around exhaust ports. Lubricate with ISO VG32
turbine oil if using non-lubricated air systems. Replace seals every 5 million
cycles under normal operation.
Critical note:
Requires 5μm filtration (40μm for emergency use only). Never apply pressure
during electrical connection/disconnection. Allow 2-minute cooldown between
continuous duty cycles exceeding 30 minutes.
| Property | Property Value |
|---|---|
| sku | 4M21008-A |
| Position | 5 Ports 2 Position |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
