Airtac 4M Solenoid Valve 4M310-08-A
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M310-08-A Solenoid Valve Technical Specifications
- Model: 4M310-08-A
- Type: 5/2-way monostable (spring return)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage variants: DC12V, DC24V, AC110V, AC220V (±10%)
- Flow capacity: 800 l/min (Cv=1.6 at 0.5 MPa)
- Response time: ≤25ms (excitation), ≤35ms (reset)
- Weight: 200g ±5% (excluding connectors)
- Dimensions: 58mm(L) × 34mm(W) × 78mm(H)
- Seal materials: HNBR/NBR (standard), FKM available on request
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Power consumption: 2.2W (AC), 2.8W (DC)
- Protection class: IP67 (dust/water resistant)
- Port thread depth: 12mm (fully engaged)
High-flow 5-port directional valve with reinforced armature system, featuring brass core construction with anodized aluminum housing. Engineered for multi-cylinder sequencing applications requiring precise directional control and rapid cycling. Incorporates dual-coil thermal protection and surge suppression circuitry. Requires ISO 8573-1:2010 Class 3 compressed air (max 50mg/m³ oil content).
- Automated assembly line clamping/unclamping systems
- Textile machinery double-acting cylinder control
- Plastic injection molding machine ejectors
- Semiconductor wafer handling robotics
- CNC machine tool pneumatic indexing tables
Installation protocol:
Mount on vibration-damped surfaces using M4 mounting screws (max torque 1.2Nm).
Maintain ≥15mm clearance from adjacent components for heat dissipation.
Lubricate pilot valve monthly with ISO VG32 turbine oil in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | 4M310-08-A |
| Position | 5 Ports 2 Position |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
