Airtac 4V Coil Terminal 4V110-017-4A
Category: Solenoid Valve Coils | Brand: AIRTAC | Series: 4V
Engineered for industrial automation systems, AIRTAC 4V solenoid valve coils feature UL-certified insulation with F/H-class temperature ratings (155°C/180°C). Compatible with 24V DC to 220V AC voltages, these coils integrate moisture-resistant epoxy resin encapsulation and IP65 protection for harsh environments. The DIN-compliant design ensures secure mounting with integrated DIN43650 connectors, while built-in surge suppression diodes enhance electrical stability. Optimized electromagnetic efficiency delivers <3W power consumption with ±10% voltage tolerance. Includes LED operation indicators and maintenance-free construction for pneumatic valve actuation in ISO 5599-1 applications.
AirTAC 4V110-017-4A Coil Terminal Specifications
- Model: 4V110-017-4A
- Type: DIN-type plug connector for solenoid valves
- Voltage rating: DC24V ±10%
- Current consumption: 0.45A (at 24VDC)
- Coil resistance: 53Ω ±10% @20℃
- Insulation resistance: ≥100MΩ (500VDC megger test)
- Temperature range: -20℃ to +70℃ (no freezing)
- Protection class: IP67 (dust/water resistant)
- Contact material: Gold-plated pins
- Housing material: PBT (UL94 V-0 flame retardant)
- Compliance: CE, RoHS
- Weight: 38g ±2g
- Dimensions: 32mm(L) × 21mm(W) × 23mm(H)
- Wire length: 150mm standard (18AWG PVC cable)
- Contact arrangement: 2-pin configuration
High-reliability coil connector designed for continuous operation in harsh environments. Features over-molded strain relief and color-coded polarity markings (blue/brown wires). The compact rectangular design enables tool-less installation with positive-lock tabs, compatible with DIN EN 175301-803 standards.
- Pneumatic valve banks in automated assembly lines
- Mobile hydraulic systems requiring vibration resistance
- Food processing equipment with frequent washdowns
- Robotic arm end-effector controls
- Electric forklight valve connections
Installation note:
Ensure proper polarity alignment (brown=+, blue=-) before energizing.
For IP67 integrity, tighten cable gland to 0.6-0.8Nm torque using
hex key. Avoid bending cable within 15mm of connector body.
