Airtac 4V Coil Terminal 4V210-016-4A
Category: Solenoid Valve Coils | Brand: AIRTAC | Series: 4V
Engineered for industrial automation systems, AIRTAC 4V solenoid valve coils feature UL-certified insulation with F/H-class temperature ratings (155°C/180°C). Compatible with 24V DC to 220V AC voltages, these coils integrate moisture-resistant epoxy resin encapsulation and IP65 protection for harsh environments. The DIN-compliant design ensures secure mounting with integrated DIN43650 connectors, while built-in surge suppression diodes enhance electrical stability. Optimized electromagnetic efficiency delivers <3W power consumption with ±10% voltage tolerance. Includes LED operation indicators and maintenance-free construction for pneumatic valve actuation in ISO 5599-1 applications.
AirTAC 4V210-016-4A Coil Terminal Technical Specifications
- Full model designation: 4V210-016-4A
- Coil type: DIN-standard plug-in solenoid coil
- Rated voltage: DC24V (±10%)
- Power consumption: 2.5W at 20℃ ambient
- Insulation class: Class F (155℃)
- Lead wire length: 150mm (standard)
- Connector type: 2-pin DIN43650 Form A
- Protection rating: IP65 (dust-tight & water jet resistant)
- Housing material: Glass-filled PBT (UL94 V-0 rated)
- Temperature range: -30℃ to +130℃ (coil surface)
- Inductance: 350mH ±10% at 1kHz
- Weight: 200g ±5% (including mounting hardware)
- Dimensions: 40mm(L) × 30mm(W) × 25mm(H)
High-performance solenoid coil engineered for continuous duty cycles in harsh environments. Features dual-coil wound construction with thermal overload protection and vibration-resistant epoxy potting. Electromagnetic shielding minimizes interference with adjacent components. Compatible with all 4V210 series valves.
- Automated assembly line clamping systems
- Plastic injection molding machine valves
- CNC tool changer pneumatic circuits
- Food processing equipment (NSF-compliant version available)
- Railway braking system actuators
Installation protocol:
Always de-energize during installation. Use torque-limited driver (0.6-0.8Nm)
for mounting screws. Maintain 15mm minimum clearance from high-current cables.
For 24/7 operation, maintain ambient temperature below 50℃.
- Surge protection: Requires external diode for DC models
- PWM compatibility: Up to 1kHz switching frequency
- Inrush current: 4.2A (typical cold start)
| Property | Property Value |
|---|---|
| sku | 4V210-016-4A |
