Airtac 4V Coil Terminal 4V210-016-5A
Category: Solenoid Valve Coils | Brand: AIRTAC | Series: 4V
Engineered for industrial automation systems, AIRTAC 4V solenoid valve coils feature UL-certified insulation with F/H-class temperature ratings (155°C/180°C). Compatible with 24V DC to 220V AC voltages, these coils integrate moisture-resistant epoxy resin encapsulation and IP65 protection for harsh environments. The DIN-compliant design ensures secure mounting with integrated DIN43650 connectors, while built-in surge suppression diodes enhance electrical stability. Optimized electromagnetic efficiency delivers <3W power consumption with ±10% voltage tolerance. Includes LED operation indicators and maintenance-free construction for pneumatic valve actuation in ISO 5599-1 applications.
AirTAC 4V210-016-5A Coil Terminal Specifications
- Model: 4V210-016-5A
- Type: 4-way, 5-port solenoid valve (direct-acting)
- Port size: G1/8 (ISO228 standard)
- Thread type: BSPP (parallel threads)
- Operating pressure range: 0.05–1.0 MPa
- Maximum pressure: 1.6 MPa
- Voltage specification: DC24V ±10% (standard), other voltages available on request
- Coil power: 1.6W (class F insulation)
- Response time: ≤15ms (excitation), ≤20ms (de-energization)
- Flow coefficient (Cv): 1.2
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (with silicone seals available for -20℃ to 150℃)
- Protection rating: IP67 (dustproof and waterproof)
- Electrical connection: DIN43650 Form A connector
- Weight: 210g ±5g (excluding cable)
- Dimensions: 52mm(L) × 36mm(W) × 68mm(H)
- Port positions: P (pressure), A/B (actuator ports), R/S (exhausts)
High-flow 4-way valve optimized for bidirectional cylinder control in industrial automation. Features low-hysteresis plunger design with copper-free aluminum alloy body for corrosion resistance. Includes manual override button for system debugging and emergency control. Requires 5μm filtered compressed air with lubricant-free operation capability.
- Pneumatic pressurization systems in semiconductor manufacturing
- Clamping/positioning mechanisms in CNC machinery
- Material handling systems with double-acting cylinders
- Cleanroom-compatible automation lines (optional low-particle version)
- Mobile hydraulic power units with vibration resistance
Installation guidelines:
Mount in vibration-free environment using M4 mounting screws (torque ≤0.8N·m).
Maintain ≥15mm clearance around exhaust ports for proper airflow.
Use thread sealant on port connections (PTFE tape not recommended).
| Property | Property Value |
|---|---|
| sku | 4V210-016-5A |
