Airtac 4V Coil Terminal 4V210-016-6A
Category: Solenoid Valve Coils | Brand: AIRTAC | Series: 4V
Engineered for industrial automation systems, AIRTAC 4V solenoid valve coils feature UL-certified insulation with F/H-class temperature ratings (155°C/180°C). Compatible with 24V DC to 220V AC voltages, these coils integrate moisture-resistant epoxy resin encapsulation and IP65 protection for harsh environments. The DIN-compliant design ensures secure mounting with integrated DIN43650 connectors, while built-in surge suppression diodes enhance electrical stability. Optimized electromagnetic efficiency delivers <3W power consumption with ±10% voltage tolerance. Includes LED operation indicators and maintenance-free construction for pneumatic valve actuation in ISO 5599-1 applications.
AirTAC 4V210-016-6A Coil Terminal Specifications
- Model: 4V210-016-6A
- Type: DIN-type solenoid coil (24VDC)
- Voltage rating: DC24V ±10%
- Power consumption: 2.2W (0.09A @24VDC)
- Insulation class: Class F (155°C)
- Protection rating: IP67 (dust/water resistant)
- Terminal type: Lead wire (3-pin DIN connector)
- Wire length: 200mm ±10mm
- Housing material: UL94 V-0 flame retardant PBT
- Temperature range: -20℃ to +120℃ (ambient)
- Duty cycle: 100% ED (continuous operation capable)
- Weight: 235g ±5g
- Dimensions: 45mm(W) × 35mm(D) × 60mm(H)
High-performance solenoid coil with reinforced epoxy encapsulation for vibration resistance. Features dual-layer insulation and surge protection circuitry, compatible with all 4V210 series valves. The optimized winding pattern ensures stable magnetic force output with ≤5% performance variance across temperature extremes.
- Automated assembly line actuators
- CNC machine tool clamping systems
- Plastic injection molding machines
- Food processing pneumatic circuits
- Battery-powered AGV braking systems
Installation note:
Use torque-controlled tools (0.5-0.6N·m) for terminal screw tightening.
Maintain minimum 15mm clearance from heat sources. Coil replacement
requires polarity verification - red wire to (+), blue wire to (-).
| Property | Property Value |
|---|---|
| sku | 4V210-016-6A |
