Airtac 4V Coil Terminal 4V210-016-8A
Category: Solenoid Valve Coils | Brand: AIRTAC | Series: 4V
Engineered for industrial automation systems, AIRTAC 4V solenoid valve coils feature UL-certified insulation with F/H-class temperature ratings (155°C/180°C). Compatible with 24V DC to 220V AC voltages, these coils integrate moisture-resistant epoxy resin encapsulation and IP65 protection for harsh environments. The DIN-compliant design ensures secure mounting with integrated DIN43650 connectors, while built-in surge suppression diodes enhance electrical stability. Optimized electromagnetic efficiency delivers <3W power consumption with ±10% voltage tolerance. Includes LED operation indicators and maintenance-free construction for pneumatic valve actuation in ISO 5599-1 applications.
AirTAC 4V210-016-8A Coil Terminal Specifications
- Model: 4V210-016-8A
- Series: 4V Compact Solenoid Valve Series
- Valve type: 5-port, 2-position (5/2-way)
- Port size: G1/8 (ISO228 standard)
- Thread type: Parallel (BSPP)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage tolerance: ±10% of rated voltage
- Voltage options:
- DC12V (3W)
- DC24V (3.2W)
- AC110V 50/60Hz (4.5VA)
- AC220V 50/60Hz (4.8VA)
- Coil insulation: Class F (155℃)
- Duty cycle: 100% continuous operation
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Weight: 215g ±5g (coil + connector)
- Dimensions: 52mm(L) × 37mm(W) × 68mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Temperature range: -20℃ to 80℃ (with no icing)
- Protection rating: IP67 (dust tight & protected against immersion)
- Electrical connection: DIN43650 Form A (standard plug)
- Pilot operation: Indirect (servo-assisted)
High-performance solenoid coil with integrated surge protection and LED operation indicator. Features military-grade epoxy encapsulation for vibration resistance (up to 10G acceleration) and moisture protection. Compatible with ISO 15407-1 standard valve bodies. Requires 5-40μm filtered compressed air with lubrication (ISO 8573-1:2010 Class 4.4.3).
- Robotic gripper actuation systems
- CNC machine tool clamping mechanisms
- Beverage canning line pneumatic controls
- Lithium battery production equipment
- Elevator brake safety circuits
Installation guidelines:
- Max allowable mounting angle: ±15° from vertical axis
- Maintain 50mm clearance from high-frequency power sources
- Use copper shielding conduit for EMI-sensitive environments
- Replace coil only when power is disconnected
| Property | Property Value |
|---|---|
| sku | 4V210-016-8A |
