Airtac 4V100 Solenoid Valve 4V110-06-E
The AirTAC Airtac 4V100 Solenoid Valve 4V110-06-E is a genuine 5/2-way single solenoid (spring return) solenoid valve with E ports and an effective area of 10.2 mm² (Cv 0.6). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.
- Valve type5/2-way
- FunctionSingle solenoid (spring return)
- Port sizeE
- Effective area10.2 mm²
- Flow (Cv)0.6
- Series4V100
About the Airtac 4V100 Solenoid Valve 4V110-06-E
The AirTAC 4V110-06E is a 5/2-way single-solenoid valve from the compact 4V100 series, built to direct compressed air to double-acting cylinders and actuators. It requires a constant AC24V electrical signal to hold the shifted position; de-energising the 4.0 VA coil allows the internal spring to return the spool, making it a safe default for applications where the cylinder must retract or stop on power loss.
With an effective area of 10.2 mm² (Cv 0.6) and a response time of 0.05 s or below, this 1/8-inch PT-ported valve suits small-bore cylinders in the O16-32 mm range. The aluminium-alloy body weighs just 120 g and supports an integrated manifold base for multi-valve groups, all rated IP65 for reliable operation in harsh industrial environments.
Airtac 4V100 Solenoid Valve 4V110-06-E Technical Specifications
| Model | Airtac 4V100 Solenoid Valve 4V110-06-E |
|---|---|
| Series | 4V100 solenoid valve (spool type) |
| Valve type | 5/2-way |
| Function | Single solenoid (spring return) |
| Port size | E |
| Exhaust port | E |
| Effective area (Cv) | 10.2 mm² (Cv 0.6) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Pilot type | Internal / external pilot |
| Operating pressure | 0.15 – 0.8 MPa |
| Proof pressure | 1.2 MPa |
| Max frequency | 5 cycle/sec |
| Response time | ≤ 0.05 s (activating) |
| Temperature | -20 to +70 °C |
| Body material | Aluminum alloy |
| Weight | 120 g |
Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Flow & Coil Options
| Effective area | 10.2 mm² |
|---|---|
| Flow coefficient | Cv 0.6 |
| Response time | ≤ 0.05 s |
| Coil power | AC 3.5 VA · DC24V 2.8 W · DC12V 2.5 W |
| Protection / insulation | IP65 (DIN40050), B-class |
| Voltage options | DC24V, DC12V, AC110V, AC220V |
| Manual override | Yes (locking / non-locking) |
Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.
Model Code: Airtac 4V100 Solenoid Valve 4V110-06-E
| 4V | Solenoid valve, spool type, 4-series. |
|---|---|
| 1 | Body size (4V100) — sets port & flow. |
| 1 | Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3. |
| -E | Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2". |
Related: 4V110 (single), 4V120 (double), 4V130C/E/P (5/3 center). Add the voltage suffix when ordering.
Where the Airtac 4V100 Solenoid Valve 4V110-06-E Is Used
Small-Part Clamping
Actuates a compact double-acting clamp on a benchtop fixture. The spring-return action ensures the clamp releases automatically when the AC24V control signal drops, protecting the workpiece.
Miniature Diverter Gates
Controls a small double-acting cylinder on a conveyor diverter for lightweight packages. The 5 c/s maximum frequency supports rapid sorting, while the 10.2 mm² effective area provides crisp actuation.
Laboratory Fluid Handling
Pilots a double-acting syringe or dispenser in an automated assay system. The AC24V coil and IP65-rated body suit the clean-but-wet environment, and the 120 g weight eases mounting on a moving gantry.
Is the Airtac 4V100 Solenoid Valve 4V110-06-E the Right Valve?
Choose the 4V110-06E when your double-acting cylinder falls within the O16-32 mm bracket and you need a spring-return action that defaults to a known position when the AC24V signal is removed. If your application demands higher speed or a larger bore, stepping up to the 4V200 series (Cv 1.0) provides the extra flow capacity.
For replacement, match all five points: body size (4V100), function (single solenoid 5/2), port and thread (1/8-inch PT), coil voltage (AC24V), and electrical entry (terminal box). This model uses the standard terminal entry; if you need a pre-wired lead, the grommet variant with an ‘I’ suffix is the alternative.
Quick checklist
- ✓ Required flow (Cv) for cylinder & speed
- ✓ Function: single / double / 5-3 center
- ✓ Coil voltage (DC24 / AC220 …)
- ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
- ✓ Single valve or manifold base?
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.8 MPa operating pressure.
- check Match coil voltage to your controller output.
- check Use the manual override to test before powering.
- check Fit silencers or fittings to the exhaust ports.
- check Wiring by qualified personnel per AirTAC docs.
Airtac 4V100 Solenoid Valve 4V110-06-E FAQ
With an effective area of 10.2 mm² (Cv 0.6), this valve suits double-acting cylinders roughly in the O16-32 mm bore range for typical automation speeds. For larger or faster cylinders, consider the 4V200 series with its higher Cv of 1.0.
The single-solenoid design needs a continuous AC24V signal to stay shifted. When power is removed, the internal spring forces the spool back to its rest position, exhausting the previously pressurised cylinder port. This provides a predictable default state without any holding current.
