Airtac 4V100 Solenoid Valve 4V110-06-F
The AirTAC Airtac 4V100 Solenoid Valve 4V110-06-F is a genuine 5/2-way single solenoid (spring return) solenoid valve with F ports and an effective area of 10.2 mm² (Cv 0.6). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.
- Valve type5/2-way
- FunctionSingle solenoid (spring return)
- Port sizeF
- Effective area10.2 mm²
- Flow (Cv)0.6
- Series4V100
About the Airtac 4V100 Solenoid Valve 4V110-06-F
The AirTAC 4V110-06F is a 5/2-way single-solenoid directional control valve built on the compact 4V100 body. It directs compressed air to one side of a double-acting cylinder or rotary actuator while exhausting the opposite side, using a spring-return mechanism that requires a constant DC12V electrical signal to hold the shifted position. When power is removed, the internal spring automatically drives the spool back to its rest state, making this a predictable choice for circuits where a fail-to-home condition is desired.
With an effective area of 10.2 mm² (Cv 0.6) and a maximum frequency of 5 cycles per second, this 120-gram valve suits ~O16-32 mm bore cylinders in compact automation. The DC12V coil draws just 2.5 W and the spool response time is 0.05 s or less. It features a terminal-box electrical entry and PT (Rc) tapered threads on the 1/8-inch ports, ready for direct plumbing into a small manifold base or stand-alone mounting.
Airtac 4V100 Solenoid Valve 4V110-06-F Technical Specifications
| Model | Airtac 4V100 Solenoid Valve 4V110-06-F |
|---|---|
| Series | 4V100 solenoid valve (spool type) |
| Valve type | 5/2-way |
| Function | Single solenoid (spring return) |
| Port size | F |
| Exhaust port | F |
| Effective area (Cv) | 10.2 mm² (Cv 0.6) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Pilot type | Internal / external pilot |
| Operating pressure | 0.15 – 0.8 MPa |
| Proof pressure | 1.2 MPa |
| Max frequency | 5 cycle/sec |
| Response time | ≤ 0.05 s (activating) |
| Temperature | -20 to +70 °C |
| Body material | Aluminum alloy |
| Weight | 120 g |
Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Flow & Coil Options
| Effective area | 10.2 mm² |
|---|---|
| Flow coefficient | Cv 0.6 |
| Response time | ≤ 0.05 s |
| Coil power | AC 3.5 VA · DC24V 2.8 W · DC12V 2.5 W |
| Protection / insulation | IP65 (DIN40050), B-class |
| Voltage options | DC24V, DC12V, AC110V, AC220V |
| Manual override | Yes (locking / non-locking) |
Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.
Model Code: Airtac 4V100 Solenoid Valve 4V110-06-F
| 4V | Solenoid valve, spool type, 4-series. |
|---|---|
| 1 | Body size (4V100) — sets port & flow. |
| 1 | Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3. |
| -F | Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2". |
Related: 4V110 (single), 4V120 (double), 4V130C/E/P (5/3 center). Add the voltage suffix when ordering.
Where the Airtac 4V100 Solenoid Valve 4V110-06-F Is Used
Small Component Clamping
Actuates a double-acting clamp on a benchtop fixture. The spring-return action ensures the clamp releases when the DC12V signal is cut, protecting parts during a power interruption.
Pick-and-Place End Effector
Controls a compact gripper on a Cartesian gantry. The 4V110-06F's 5 c/s cycle rate and 0.05 s response keep pace with rapid pick-and-place sequences on small assembly lines.
Laboratory Fluid Handling
Directs a small double-acting syringe pump or actuator in an analytical instrument. The low 2.5 W DC12V coil and IP65-rated terminal box suit clean, low-voltage control cabinets.
Is the Airtac 4V100 Solenoid Valve 4V110-06-F the Right Valve?
Choose the 4V110-06F when you need a single-solenoid 5/2 with a DC12V coil and 1/8-inch PT ports. The spring-return design is ideal for tasks where the valve must default to a known position on power loss—such as a clamp that should retract during an E-stop. If your cylinder bore exceeds ~32 mm or you need a faster fill, step up to the 4V200 series (Cv 1.0) for higher flow capacity.
For a direct replacement, match five points: body size (4V100), function (single 5/2, code 10), port and thread (1/8-inch PT), coil voltage (DC12V, code F), and electrical entry (terminal box). If you are building a multi-valve assembly, this unit mounts on a 4V100-series manifold base to create a clean, integrated air circuit with shared supply and exhaust.
Quick checklist
- ✓ Required flow (Cv) for cylinder & speed
- ✓ Function: single / double / 5-3 center
- ✓ Coil voltage (DC24 / AC220 …)
- ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
- ✓ Single valve or manifold base?
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.8 MPa operating pressure.
- check Match coil voltage to your controller output.
- check Use the manual override to test before powering.
- check Fit silencers or fittings to the exhaust ports.
- check Wiring by qualified personnel per AirTAC docs.
Airtac 4V100 Solenoid Valve 4V110-06-F FAQ
With a Cv of 0.6 and an effective area of 10.2 mm², this valve is sized for double-acting cylinders in the ~O16-32 mm bore range. For larger cylinders or higher-speed applications, a 4V200-series valve (Cv 1.0) will provide a more responsive fill and exhaust cycle.
The 4V110-06F is a single-solenoid, spring-return valve. When the DC12V signal is removed, the internal spring mechanically pushes the spool back to its home position, exhausting the previously pressurized cylinder port. It does not hold its last position—for that behavior, consider a double-solenoid 4V120 model.
