Airtac 4V100 Solenoid Valve 4V11006BI-AM
1. Pilot operation: Selectable internal pilot or external pilot configuration;
2. Spool-type structure ensures excellent sealing performance and rapid response;
3. Three-position variants offer three distinct center-position functions;
4. Double solenoid 5/2-way configuration features latching (memory) function;
5. Special bore machining process minimizes friction resistance, achieves low actuation pressure (0.15MPa), and extends service life;
6. Lubrication-free operation;
7. Integrable with manifold bases for space-optimized valve arrangements;
8. Manual override provided for simplified installation and commissioning;
9. Multiple standard voltage options available (AC/DC).
Category: Solenoid Valves | Brand: AIRTAC | Series: 4V100
AirTAC 4V100 Series Solenoid Valve 4V11006BI-AM Technical Details
- Full model designation: 4V11006BI-AM (ISO standard coding)
- Valve type: 5-port 2-position (5/2-way) double solenoid
- Operation method: Double electric pilot with spring return
- Port thread: G1/4 (ISO228 standard) with BSPP connections
- Effective area ratio: 1:1.15 (optimized for balanced pressure operation)
- Operating pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC24V (±10%) / AC110V 50/60Hz / AC220V 50/60Hz
- Coil insulation class: Class F (155°C thermal rating)
- Seal material: NBR (Nitrile) for general use / Optional FKM seals available
- Ambient temperature: -5℃ to 60℃ (with humidity <85% RH)
- Flow capacity: 850 l/min (Cv=1.3 at 0.5MPa)
- Response time: ≤15ms (at rated voltage)
- Protection grade: IP65 (dust-tight & water jet resistant)
- Electrical connection: DIN43650 Form A with LED indicator
- Weight: 280g ±5% (excluding accessories)
- Dimensions: 68mm(L) × 34mm(W) × 63mm(H) (manifold interface excluded)
High-flow directional control valve featuring low power consumption (1.6W holding power) and corrosion-resistant anodized aluminum body. Designed for bi-directional pneumatic circuit control with manual override capability. Requires 5μm filtered lubricated air (ISO8573-1 class 4) and regular maintenance every 10M cycles.
- Plastic injection molding machine clamp controls
- Automated assembly line actuator sequencing
- CNC machine tool chuck mechanisms
- Food processing pneumatic systems (with optional FDA seals)
- High-cycle packaging equipment (≥5M cycles/year)
Installation guidelines:
Mount on ISO standard manifold using 1.5Nm torque. Maintain 20mm
clearance below valve for heat dissipation. Lubricate monthly with
ISO VG32 turbine oil if using non-lubricated air systems.
- Manifold block: MXQ4-10S
- Quick connector: QST-4-M5
- Silencer: AS-0422 (35dB noise reduction)
| Property | Property Value |
|---|---|
| sku | 4V11006BI-AM |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
