Airtac 4V100 Solenoid Valve 4V120-06-C
1. Pilot operation: Selectable internal pilot or external pilot configuration;
2. Spool-type structure ensures excellent sealing performance and rapid response;
3. Three-position variants offer three distinct center-position functions;
4. Double solenoid 5/2-way configuration features latching (memory) function;
5. Special bore machining process minimizes friction resistance, achieves low actuation pressure (0.15MPa), and extends service life;
6. Lubrication-free operation;
7. Integrable with manifold bases for space-optimized valve arrangements;
8. Manual override provided for simplified installation and commissioning;
9. Multiple standard voltage options available (AC/DC).
Category: Solenoid Valves | Brand: AIRTAC | Series: 4V100
AirTAC 4V120-06-C Solenoid Valve Technical Details
- Model: 4V120-06-C
- Valve type: 5/2-way, double solenoid (dual coil)
- Port configuration: PT1/8 (G1/8 equivalent available)
- Operating pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 750 l/min (ANR) at 0.5 MPa
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: Heat-resistant NBR (-5℃ to 80℃)
- Body material: Reinforced PBT with glass fiber
- Protection class: IP67 (dust/water resistant)
- Electrical connection: DIN43650 Form A connector
- Weight: 235g ±5g (with connectors)
- Dimensions: 52mm(L) × 34mm(W) × 67mm(H)
High-flow bistable solenoid valve featuring energy-saving dual coil design that maintains position without continuous power. The 4V120 series incorporates a manual override button for system debugging and includes built-in surge protection diodes. Requires 5μm filtered lubricated air (ISO 8573-1 class 4) with recommended viscosity ISO VG32.
- Automated assembly line actuators
- Plastic injection molding machine clamps
- CNC tool changers with position memory
- Robotic gripper systems requiring dual-action control
- Textile machinery air-jet looms
Installation guidelines:
Maintain horizontal mounting orientation for optimal drainage.
Use copper-free anti-vibration brackets in high-cycle applications (>1M operations/year).
Allow 15mm clearance on sides for heat dissipation.
| Property | Property Value |
|---|---|
| sku | 4V120-06-C |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | AC 110V |
