Airtac 4V100 Solenoid Valve 4V120-06-F
1. Pilot operation: Selectable internal pilot or external pilot configuration;
2. Spool-type structure ensures excellent sealing performance and rapid response;
3. Three-position variants offer three distinct center-position functions;
4. Double solenoid 5/2-way configuration features latching (memory) function;
5. Special bore machining process minimizes friction resistance, achieves low actuation pressure (0.15MPa), and extends service life;
6. Lubrication-free operation;
7. Integrable with manifold bases for space-optimized valve arrangements;
8. Manual override provided for simplified installation and commissioning;
9. Multiple standard voltage options available (AC/DC).
Category: Solenoid Valves | Brand: AIRTAC | Series: 4V100
AirTAC 4V120-06-F Solenoid Valve Technical Specifications
- Model Series: 4V100 (High Flow Compact Series)
- Valve Type: 5/2-way single solenoid pilot-operated
- Port Configuration: 5 ports (P, A, B, EA, EB) / 2 positions
- Port Size: G1/8 (BSPP thread standard)
- Operating Pressure Range: 0.15–1.0 MPa (21.7–145 psi)
- Max Flow Rate: 1000 L/min (ANR) at 0.5 MPa
- Voltage Options: DC12V, DC24V, AC110V 50/60Hz, AC220V 50/60Hz
- Power Consumption: 1.8W (DC) / 3.5VA (AC)
- Response Time: ≤15ms (energized), ≤20ms (de-energized)
- Seal Material: Heat-resistant NBR (Nitrile) -70% improved durability vs standard NBR
- Temperature Range: -5℃ to 80℃ (with intermittent operation up to 120℃ for ≤5 mins)
- Protection Rating: IP67 (dust tight & protected against temporary immersion)
- Weight: 340g ±5g (with connector)
- Dimensions: 57mm(L) × 38mm(W) × 74mm(H) (excluding mounting accessories)
- Port Thread Depth: 10mm (full thread engagement recommended)
- Compatible Fluids: Compressed air (oil mist lubrication ≤1:13,000)
High-flow directional control valve featuring dual-pressure balanced spool design for consistent performance under fluctuating line pressures. The 4V120-06-F incorporates a manual override button with 45° rotation lock mechanism and hardened stainless steel plunger for 500,000+ cycle durability. Requires 5μm filtered air with dew point -20℃ below ambient.
- High-speed pick-and-place automation systems
- Pneumatic cylinder sequencing in automotive assembly lines
- Plastic injection molding machine clamp controls
- Textile machinery air circuit switching
- Semiconductor wafer handling vacuum/pressure systems
Installation Guidelines:
Mount with vibration-damping brackets in high-shock environments. For vertical mounting,
position coil upward to prevent debris accumulation. Use copper-free lubricants (ISO VG32
equivalent) for maintenance. Allow 15mm clearance around exhaust ports for heat dissipation.
| Property | Property Value |
|---|---|
| sku | 4V120-06-F |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | DC12V |
