Airtac 4V100 Solenoid Valve 4V120-M5-A
1. Pilot operation: Selectable internal pilot or external pilot configuration;
2. Spool-type structure ensures excellent sealing performance and rapid response;
3. Three-position variants offer three distinct center-position functions;
4. Double solenoid 5/2-way configuration features latching (memory) function;
5. Special bore machining process minimizes friction resistance, achieves low actuation pressure (0.15MPa), and extends service life;
6. Lubrication-free operation;
7. Integrable with manifold bases for space-optimized valve arrangements;
8. Manual override provided for simplified installation and commissioning;
9. Multiple standard voltage options available (AC/DC).
Category: Solenoid Valves | Brand: AIRTAC | Series: 4V100
AirTAC 4V120-M5-A 5/2-Way Solenoid Valve Technical Details
- Model series: 4V100 platform
- Valve configuration: 5/2-way (double solenoid)
- Port thread: M5×0.8 (ISO standard)
- Port configuration: 5 ports (P: pressure, A/B: outlets, R/S: exhausts)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Maximum flow rate: 850 l/min (Cv≈1.2)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (at rated voltage)
- Seal material: Heat-resistant NBR (-5℃ to 80℃)
- Body material: Reinforced PBT with UL94 V-0 rating
- Protection class: IP67 (dustproof & temporary immersion)
- Weight: 210g ±5g (with connectors)
- Dimensions: 52mm(L) × 34mm(W) × 65mm(H) (excluding fittings)
- Mounting orientation: Any (horizontal/vertical recommended)
- Service life: ≥10 million cycles (under rated conditions)
High-flow 5/2-way solenoid valve optimized for bidirectional cylinder control in automated systems. Features dual manual override buttons, surge suppression circuitry, and LED operation indicators. Requires 5μm filtered lubricated air (ISO 8573-1:2010 class 4). Compatible with ISO 5599-1 mounting interfaces.
- Pneumatic clamping systems in CNC machinery
- Actuator control for automated assembly lines
- Material handling equipment (rotary indexers, conveyors)
- Textile machinery tension control systems
- Plastic injection molding ejector mechanisms
Installation guidelines:
Use anti-vibration mounting brackets in high-cycle applications (>2Hz).
Maintain minimum 15mm clearance from adjacent components for heat dissipation.
Always install downstream water separator when ambient humidity exceeds 80% RH.
- APV-02M muffler (for exhaust ports)
- ASV-5M bracket set for DIN rail mounting
- APG-04M pressure gauge kit
| Property | Property Value |
|---|---|
| sku | 4V120-M5-A |
| Position | 5 Ports 2 Position |
| Port Size | M5 |
| Standard Voltage | AC220V |
