AirTAC 4V410-15AI Solenoid Valve, 5/2-way, PT1/2, AC220V, grommet entry (4V41015AI)
The AirTAC AirTAC 4V410-15AI Solenoid Valve, 5/2-way, PT1/2, AC220V, grommet entry (4V41015AI) is a genuine 5/2-way single solenoid (spring return) solenoid valve with 41015AI ports and an effective area of 48.0 mm² (Cv 2.82). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.
- Valve type5/2-way
- FunctionSingle solenoid (spring return)
- Port size41015AI
- Effective area48.0 mm²
- Flow (Cv)2.82
- Series4V400
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC 4V410-15AI Solenoid Valve, 5/2-way, PT1/2, AC220V, grommet entry (4V41015AI)
The AirTAC 4V410-15AI is a 5/2-way single-solenoid directional control valve that directs compressed air to double-acting cylinders and rotary actuators. It requires a constant AC220V electrical signal to hold the shifted position; de-energising the coil immediately returns the spool to its home state via a mechanical spring, making it a predictable choice for cycles where a fail-to-home condition is desired. This variant is factory-fitted with a grommet-style electrical entry, providing a 0.5 m flying lead for direct DIN-connector-free wiring.
Built on the largest 4V body, the 4V400 series delivers an effective area of 48.0 mm² (Cv 2.82), suiting it to bore sizes roughly in the O80–125 mm range. The AC220V coil draws 4.5 VA inrush, and the aluminium-alloy body keeps the unit weight to 590 g. With a response time of 0.05 seconds or below and IP65 protection, it integrates easily into manifold groups or standalone piping on heavy automation cells.
AirTAC 4V410-15AI Solenoid Valve, 5/2-way, PT1/2, AC220V, grommet entry (4V41015AI) Technical Specifications
| Model | AirTAC 4V410-15AI Solenoid Valve, 5/2-way, PT1/2, AC220V, grommet entry (4V41015AI) |
|---|---|
| Series | 4V400 solenoid valve (spool type) |
| Valve type | 5/2-way |
| Function | Single solenoid (spring return) |
| Port size | 41015AI |
| Exhaust port | 41015AI |
| Effective area (Cv) | 48.0 mm² (Cv 2.82) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Pilot type | Internal / external pilot |
| Operating pressure | 0.15 – 0.8 MPa |
| Proof pressure | 1.2 MPa |
| Max frequency | 3 cycle/sec |
| Response time | ≤ 0.05 s (activating) |
| Temperature | -20 to +70 °C |
| Body material | Aluminum alloy |
| Weight | 590 g |
Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Flow & Coil Options
| Effective area | 48.0 mm² |
|---|---|
| Flow coefficient | Cv 2.82 |
| Response time | ≤ 0.05 s |
| Coil power | AC 4.5 VA · DC24V 3.0 W · DC12V 2.5 W |
| Protection / insulation | IP65 (DIN40050), B-class |
| Voltage options | DC24V, DC12V, AC110V, AC220V |
| Manual override | Yes (locking / non-locking) |
Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.
Model Code: AirTAC 4V410-15AI Solenoid Valve, 5/2-way, PT1/2, AC220V, grommet entry (4V41015AI)
| 4V | Solenoid valve, spool type, 4-series. |
|---|---|
| 4 | Body size (4V400) — sets port & flow. |
| 1 | Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3. |
| -41015AI | Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2". |
Related: 4V410 (single), 4V420 (double), 4V430C/E/P (5/3 center). Add the voltage suffix when ordering.
Where the AirTAC 4V410-15AI Solenoid Valve, 5/2-way, PT1/2, AC220V, grommet entry (4V41015AI) Is Used
Large Clamp & Press Sequences
Directs a double-acting clamp cylinder on a welding fixture or stamping press. The spring-return action ensures the clamp retracts on power loss, while the AC220V grommet lead simplifies wiring inside crowded control cabinets.
Palletiser & Conveyor Diverters
Shifts a heavy diverter gate powered by an O100 cylinder. The 4V410-15AI’s Cv 2.82 provides the rapid fill and exhaust needed to keep pace with high-throughput sortation lines.
Dusty Plant Environments
With IP65 protection and a sealed grommet entry, this valve withstands washdown overspray and airborne particulates. It reliably cycles a double-acting sweep arm on a lumber mill or cement bagging station.
Is the AirTAC 4V410-15AI Solenoid Valve, 5/2-way, PT1/2, AC220V, grommet entry (4V41015AI) the Right Valve?
Choose the 4V410-15AI when your application needs a spring-return 5/2 function with a pre-wired AC220V supply. The grommet entry eliminates the need for a separate DIN connector, speeding up panel-less installations. If your cylinder is smaller—typically under O63 bore—stepping down to the 4V300 series (Cv 1.65) often yields a more economical match without sacrificing cycle speed.
For a drop-in replacement, match five points: the 4V400 body size, the 10 (single-solenoid) function, the 1/2 in. port with PT thread, AC220V coil voltage, and the grommet electrical entry. If you later need a still larger flow path than the 4V400’s 48.0 mm² effective area, consider moving to a bigger valve series or ganging multiple 4V400 units on a common manifold.
Quick checklist
- ✓ Required flow (Cv) for cylinder & speed
- ✓ Function: single / double / 5-3 center
- ✓ Coil voltage (DC24 / AC220 …)
- ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
- ✓ Single valve or manifold base?
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.8 MPa operating pressure.
- check Match coil voltage to your controller output.
- check Use the manual override to test before powering.
- check Fit silencers or fittings to the exhaust ports.
- check Wiring by qualified personnel per AirTAC docs.
AirTAC 4V410-15AI Solenoid Valve, 5/2-way, PT1/2, AC220V, grommet entry (4V41015AI) FAQ
With an effective area of 48.0 mm² (Cv 2.82), it is typically paired with double-acting cylinders in the O80 to O125 mm bore range. The exact speed depends on supply pressure, tubing diameter and load inertia, but the valve’s 3 cycles/sec maximum frequency supports brisk reciprocating motions.
The ‘I’ suffix designates a grommet-style entry with a 0.5 m flying lead, allowing you to connect directly to a control panel without a DIN 43650 connector. The coil still consumes 4.5 VA at 220 V AC, but the wiring path is slimmer and often preferred where space above the valve is tight.
