AirTAC 4V410-15 Solenoid Valve, 4V400 Series (4V41015BG-W)
The AirTAC AirTAC 4V410-15 Solenoid Valve, 4V400 Series (4V41015BG-W) is a genuine 5/2-way single solenoid (spring return) solenoid valve with W ports and an effective area of 48.0 mm² (Cv 2.82). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.
- Valve type5/2-way
- FunctionSingle solenoid (spring return)
- Port sizeW
- Effective area48.0 mm²
- Flow (Cv)2.82
- Series4V400
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC 4V410-15 Solenoid Valve, 4V400 Series (4V41015BG-W)
The 4V41015BG-W is AirTAC's 4V400 flagship 5/2-way single-solenoid valve in the external-pilot (-W) build, fitted with a 1/2in G (BSPP parallel) port and a DC24V coil drawing 3.0W through a terminal box. It directs compressed air to double-acting cylinders and actuators: energise the solenoid and the spool shifts to extend the cylinder; cut the signal and the spring returns the spool, sending pressure to the rod side to retract it. Because the pilot air is fed through a separate external pilot port rather than tapped internally from the main line, the spool still shifts cleanly even when main-line pressure is low or the circuit runs under vacuum or reduced supply conditions.
This is the highest-flow 4V body AirTAC makes, with an effective area of 48 mm2 (Cv 2.82) and a maximum cycling rate of 3 cycles per second, so it comfortably drives cylinder bores in the ~O80-125 mm class. Activation time is 0.05 s or better, and the complete valve weighs just 590 g. Like every 4V400 valve it is IP65 protected, runs on 0.15-0.8 MPa of air filtered by a 40 um element, needs no lubrication, and can be banked into an integrated manifold on a common base.
AirTAC 4V410-15 Solenoid Valve, 4V400 Series (4V41015BG-W) Technical Specifications
| Model | AirTAC 4V410-15 Solenoid Valve, 4V400 Series (4V41015BG-W) |
|---|---|
| Series | 4V400 solenoid valve (spool type) |
| Valve type | 5/2-way |
| Function | Single solenoid (spring return) |
| Port size | W |
| Exhaust port | W |
| Effective area (Cv) | 48.0 mm² (Cv 2.82) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Pilot type | Internal / external pilot |
| Operating pressure | 0.15 – 0.8 MPa |
| Proof pressure | 1.2 MPa |
| Max frequency | 3 cycle/sec |
| Response time | ≤ 0.05 s (activating) |
| Temperature | -20 to +70 °C |
| Body material | Aluminum alloy |
| Weight | 590 g |
Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Flow & Coil Options
| Effective area | 48.0 mm² |
|---|---|
| Flow coefficient | Cv 2.82 |
| Response time | ≤ 0.05 s |
| Coil power | AC 4.5 VA · DC24V 3.0 W · DC12V 2.5 W |
| Protection / insulation | IP65 (DIN40050), B-class |
| Voltage options | DC24V, DC12V, AC110V, AC220V |
| Manual override | Yes (locking / non-locking) |
Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.
Model Code: AirTAC 4V410-15 Solenoid Valve, 4V400 Series (4V41015BG-W)
| 4V | Solenoid valve, spool type, 4-series. |
|---|---|
| 4 | Body size (4V400) — sets port & flow. |
| 1 | Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3. |
| -W | Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2". |
Related: 4V410 (single), 4V420 (double), 4V430C/E/P (5/3 center). Add the voltage suffix when ordering.
Where the AirTAC 4V410-15 Solenoid Valve, 4V400 Series (4V41015BG-W) Is Used
Vacuum and low-pressure material handling
External piloting keeps the spool switching reliably on circuits where main-line pressure is low or under vacuum, such as suction frames and lifters moving sheet stock, panels and cartons on packaging and palletising lines.
Heavy clamping and press cylinders
With Cv 2.82 behind it, the valve feeds large clamping and light-press cylinders in the ~O80-125 mm range, delivering the flow needed for fast close/open cycles on fixtures, jigs and forming stations.
Large-bore actuation on process lines
Diverters, pushers, gates and lifters driven by big double-acting cylinders cycle at up to 3 per second on this body, with the spring-return function guaranteeing the cylinder retracts whenever the 24V signal drops.
Is the AirTAC 4V410-15 Solenoid Valve, 4V400 Series (4V41015BG-W) the Right Valve?
Match your cylinder bore first. At Cv 2.82 this valve is sized for large bores around O80-125 mm; if your cylinder is O63 or smaller, the 4V300 (Cv 1.65) will cycle it faster and cheaper, while this body would be oversized. If your application moves even more air than the 4V400 class, you are beyond the 4V range and should move to a larger valve series or a manifold arrangement. Choose this -W external-pilot version when your supply pressure can dip, when the valve sits downstream of a vacuum generator, or when you want pilot supply isolated from main-line fluctuations; on stable full-pressure lines the standard internally-piloted 4V410-15BG does the same job.
Ordering a replacement comes down to five points: body size (4V400), function (single solenoid 5/2 with spring return), port and thread (1/2in, G parallel here - PT and NPT variants exist), coil voltage (DC24V, 3.0W), and electrical entry (terminal box). Match all five and the valve drops straight in.
Quick checklist
- ✓ Required flow (Cv) for cylinder & speed
- ✓ Function: single / double / 5-3 center
- ✓ Coil voltage (DC24 / AC220 …)
- ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
- ✓ Single valve or manifold base?
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.8 MPa operating pressure.
- check Match coil voltage to your controller output.
- check Use the manual override to test before powering.
- check Fit silencers or fittings to the exhaust ports.
- check Wiring by qualified personnel per AirTAC docs.
AirTAC 4V410-15 Solenoid Valve, 4V400 Series (4V41015BG-W) FAQ
It is a 5/2-way valve for double-acting cylinders and actuators, sized around an effective area of 48 mm2 (Cv 2.82), which suits bores of roughly O80-125 mm. The -W suffix means pilot air is supplied through a separate external port instead of being taken from the main supply internally, so switching stays dependable when line pressure is low or the circuit operates under vacuum.
One solenoid shifts the spool while energised; when you cut the DC24V signal (coil draws 3.0W), the internal spring returns the spool and the cylinder retracts. That makes it ideal wherever the valve must fail back to a known position on signal loss. For an equivalent valve that holds its position through a power outage, you would need the double-solenoid 4V420 memory type instead.
