AirTAC 4V410-15F Solenoid Valve, 5/2-way, PT1/2, DC12V, terminal entry (4V41015F)
The AirTAC AirTAC 4V410-15F Solenoid Valve, 5/2-way, PT1/2, DC12V, terminal entry (4V41015F) is a genuine 5/2-way single solenoid (spring return) solenoid valve with 41015F ports and an effective area of 48.0 mm² (Cv 2.82). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.
- Valve type5/2-way
- FunctionSingle solenoid (spring return)
- Port size41015F
- Effective area48.0 mm²
- Flow (Cv)2.82
- Series4V400
About the AirTAC 4V410-15F Solenoid Valve, 5/2-way, PT1/2, DC12V, terminal entry (4V41015F)
The 4V410-15F is a 5/2-way single-solenoid valve from the AirTAC 4V400 series, designed to direct compressed air to large double-acting cylinders and actuators. Its spool shifts when the DC12V coil is energized, and a mechanical spring returns it to the home position the moment power is cut—making it a fail-safe choice for applications where the cylinder must retract or stop on signal loss.
With a substantial effective area of 48.0 mm² (Cv 2.82), this body size suits cylinders in the ~Ø80–125 mm range. The DC12V coil draws just 2.5 W of power, keeping heat low inside the terminal-box wiring enclosure. The aluminum-alloy body weighs 590 g, and the sliding-column design delivers a crisp response time of 0.05 seconds or less.
AirTAC 4V410-15F Solenoid Valve, 5/2-way, PT1/2, DC12V, terminal entry (4V41015F) Technical Specifications
| Model | AirTAC 4V410-15F Solenoid Valve, 5/2-way, PT1/2, DC12V, terminal entry (4V41015F) |
|---|---|
| Series | 4V400 solenoid valve (spool type) |
| Valve type | 5/2-way |
| Function | Single solenoid (spring return) |
| Port size | 41015F |
| Exhaust port | 41015F |
| Effective area (Cv) | 48.0 mm² (Cv 2.82) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Pilot type | Internal / external pilot |
| Operating pressure | 0.15 – 0.8 MPa |
| Proof pressure | 1.2 MPa |
| Max frequency | 3 cycle/sec |
| Response time | ≤ 0.05 s (activating) |
| Temperature | -20 to +70 °C |
| Body material | Aluminum alloy |
| Weight | 590 g |
Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Flow & Coil Options
| Effective area | 48.0 mm² |
|---|---|
| Flow coefficient | Cv 2.82 |
| Response time | ≤ 0.05 s |
| Coil power | AC 4.5 VA · DC24V 3.0 W · DC12V 2.5 W |
| Protection / insulation | IP65 (DIN40050), B-class |
| Voltage options | DC24V, DC12V, AC110V, AC220V |
| Manual override | Yes (locking / non-locking) |
Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.
Model Code: AirTAC 4V410-15F Solenoid Valve, 5/2-way, PT1/2, DC12V, terminal entry (4V41015F)
| 4V | Solenoid valve, spool type, 4-series. |
|---|---|
| 4 | Body size (4V400) — sets port & flow. |
| 1 | Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3. |
| -41015F | Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2". |
Related: 4V410 (single), 4V420 (double), 4V430C/E/P (5/3 center). Add the voltage suffix when ordering.
Where the AirTAC 4V410-15F Solenoid Valve, 5/2-way, PT1/2, DC12V, terminal entry (4V41015F) Is Used
Heavy-Duty Clamping
Controls a large-bore double-acting clamp cylinder on a 12 V DC mobile or off-grid fixture. The spring return guarantees the clamp releases when the signal drops.
Tail-Lift Gate Actuation
Powers the main lift cylinder on a truck tail-lift running from the vehicle's 12 V electrical system. The high Cv of 2.82 ensures smooth, rapid movement of the heavy platform.
Press Safety Interlock
Drives a double-acting gate or guard cylinder on a small hydraulic press. The single-solenoid, spring-return design retracts the guard immediately if the 12 V control signal is interrupted.
Is the AirTAC 4V410-15F Solenoid Valve, 5/2-way, PT1/2, DC12V, terminal entry (4V41015F) the Right Valve?
Choose the 4V410-15F when your system runs on a 12 V DC power bus and you need a spring-return action that automatically exhausts the cylinder's working port on de-energization. If you are driving a smaller cylinder—say Ø50–63 mm—the 4V300 series (Cv 1.65) is a better match and avoids oversizing the valve.
As the largest body in the 4V family, the 4V400 is the go-to for half-inch lines. When replacing an existing valve, match five points: the 4V400 body size, the single-solenoid 5/2 function, the 1/2" PT (Rc) tapered thread, a DC12V coil, and the terminal-box electrical entry. For still higher flow, consider a manifolded group of 4V400 valves or step up to a larger valve series.
Quick checklist
- ✓ Required flow (Cv) for cylinder & speed
- ✓ Function: single / double / 5-3 center
- ✓ Coil voltage (DC24 / AC220 …)
- ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
- ✓ Single valve or manifold base?
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.8 MPa operating pressure.
- check Match coil voltage to your controller output.
- check Use the manual override to test before powering.
- check Fit silencers or fittings to the exhaust ports.
- check Wiring by qualified personnel per AirTAC docs.
AirTAC 4V410-15F Solenoid Valve, 5/2-way, PT1/2, DC12V, terminal entry (4V41015F) FAQ
With a Cv of 2.82 and an effective area of 48.0 mm², it is typically well-suited for double-acting cylinders with a bore between approximately 80 mm and 125 mm. The exact speed depends on your operating pressure and tubing layout.
Yes. The single-solenoid design needs a constant 12 V DC signal to hold the valve in its actuated position. When power is removed, the internal spring forces the spool back to its rest state, exhausting the cylinder's previously pressurized port.
