Airtac 4V400 Solenoid Valve 4V41015H-AM
2. Spool-type structure with excellent sealing performance and rapid response characteristics;
3. Three-position solenoid valve offers three center configuration options: closed center, exhausted center, and pressure center;
4. Dual-coil two-position configuration features latching (memory) function;
5. Precision-machined bore with low friction design ensures minimal actuation pressure and extended service life;
6. Maintenance-free operation without lubrication requirements;
7. Manifold-mountable design for space-efficient system integration;
8. Integrated manual override for simplified commissioning and troubleshooting;
9. Multiple standard voltage configurations available.
Category: Solenoid Valves | Brand: AirTAC | Series: 4V400
AirTAC 4V400 Solenoid Valve 4V41015H-AM Technical Specifications
- Model: 4V41015H-AM
- Type: 5/2-way double solenoid (monostable)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–1.0 MPa
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤25ms (actuation), ≤35ms (release)
- Flow coefficient (Cv): 2.3
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Ambient temperature range: -10℃ to 60℃ (with anti-freeze measures below 0℃)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Protection standard: IP67 (dust/water resistant)
- Weight: 470g ±5%
- Dimensions: 78mm(L) × 44mm(W) × 96mm(H)
High-flow directional control valve with dual coil redundancy, engineered for industrial automation requiring rapid cycling. Features an aluminum alloy body with hard anodized coating for chemical resistance. The "H" suffix indicates enhanced heat tolerance (up to 60℃ ambient), while "AM" denotes manual override capability. Requires 5μm filtration with oil mist lubrication (ISO VG32 recommended).
- Plastic injection molding machine clamp controls
- Automated assembly line actuators
- Textile machinery cylinder sequencing
- Semiconductor wafer handling robots
- Beverage canning line pneumatic systems
Installation guidelines:
Mount in vibration-free environments using M5 mounting screws (torque ≤0.8N·m).
Maintain 20mm clearance above valve for heat dissipation. Use shielded cables
when operating near frequency inverters. Lubricate every 5 million cycles.
| Property | Property Value |
|---|---|
| sku | 4V41015H-AM |
| Position | 5 Ports 2 Position |
| Port Size | PT 1/2 |
| Standard Voltage | DC24V |
