Airtac 4V400 Solenoid Valve 4V430P-15-A
The AirTAC Airtac 4V400 Solenoid Valve 4V430P-15-A is a genuine 5/3-way 5/3 double solenoid — pressure center solenoid valve with A ports and an effective area of 40.0 mm² (Cv 2.35). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.
- Valve type5/3-way
- Function5/3 double solenoid — Pressure center
- Port sizeA
- Effective area40.0 mm²
- Flow (Cv)2.35
- Series4V400
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 4V400 Solenoid Valve 4V430P-15-A
The AirTAC 4V430P-15A is a 5/3-way double-solenoid valve built on the largest 4V body, directing compressed air to double-acting cylinders and actuators with a 1/2-inch port. Its pressure-center spool applies supply pressure to both cylinder ports when the valve returns to mid-position, which counterbalances the piston and resists external forces—useful when you need to hold a load against a consistent push without drifting.
This AC220V model uses a terminal-box electrical entry and draws 4.5 VA inrush, making it straightforward to wire into standard machine panels. With an effective area of 40.0 mm² (Cv 2.35), a 3 cycles/sec maximum frequency, and a response time of 0.05 s or below, the 4V430P-15A suits ~Ø80–125 mm cylinders in circuits where a centered, pressured state is the safest default.
Airtac 4V400 Solenoid Valve 4V430P-15-A Technical Specifications
| Model | Airtac 4V400 Solenoid Valve 4V430P-15-A |
|---|---|
| Series | 4V400 solenoid valve (spool type) |
| Valve type | 5/3-way |
| Function | 5/3 double solenoid — Pressure center |
| Port size | A |
| Exhaust port | A |
| Effective area (Cv) | 40.0 mm² (Cv 2.35) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Pilot type | Internal / external pilot |
| Operating pressure | 0.15 – 0.8 MPa |
| Proof pressure | 1.2 MPa |
| Max frequency | 3 cycle/sec |
| Response time | ≤ 0.05 s (activating) |
| Temperature | -20 to +70 °C |
| Body material | Aluminum alloy |
| Weight | 770 g |
Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Flow & Coil Options
| Effective area | 40.0 mm² |
|---|---|
| Flow coefficient | Cv 2.35 |
| Response time | ≤ 0.05 s |
| Coil power | AC 4.5 VA · DC24V 3.0 W · DC12V 2.5 W |
| Protection / insulation | IP65 (DIN40050), B-class |
| Voltage options | DC24V, DC12V, AC110V, AC220V |
| Manual override | Yes (locking / non-locking) |
Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.
Model Code: Airtac 4V400 Solenoid Valve 4V430P-15-A
| 4V | Solenoid valve, spool type, 4-series. |
|---|---|
| 4 | Body size (4V400) — sets port & flow. |
| 3 | Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3. |
| -A | Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2". |
Related: 4V410 (single), 4V420 (double), 4V430C/E/P (5/3 center). Add the voltage suffix when ordering.
Where the Airtac 4V400 Solenoid Valve 4V430P-15-A Is Used
Counter-Balanced Press Tools
In a pneumatic press where the tooling must hold position against a constant spring-return force, the 4V430P-15A's pressure center applies equal pressure to both sides of the cylinder at mid-stroke, preventing creep and keeping the tool precisely where it was stopped.
Large-Bore Gate Stops
For a material-handling gate on a conveyor that must resist product weight pushing back when paused, this valve's centered pressure state locks the double-acting cylinder in place with balanced force, so the gate doesn't drift open under load.
Heavy Clamping with Anti-Backdrive
When a clamp on an Ø100 mm cylinder must hold a workpiece against a steady machining force, the pressure-center spool keeps both A and B ports pressurized at rest. This counter-pressure stops the clamp from backing off, even if air supply fluctuates slightly.
Is the Airtac 4V400 Solenoid Valve 4V430P-15-A the Right Valve?
Choose the 4V430P-15A when your double-acting cylinder needs to stop at mid-stroke under balanced pressure—this prevents the rod from being back-driven by a steady opposing force. If your cylinder is smaller (~Ø40–63 mm) and you don't need the pressure-center feature, stepping down to the 4V300 series (Cv 1.65) often saves space and cost. For flow beyond the 4V400's 40.0 mm² effective area, consider a larger valve series or a manifolded group.
When replacing an existing 5/3 pressure-center valve, match five points: body size (4V400), function (30P), port and thread (1/2-inch PT), coil voltage (AC220V), and electrical entry (terminal box). A mismatch on any of these—especially the center condition—will change the actuator's fail-safe behavior, so verify the original part number carefully.
Quick checklist
- ✓ Required flow (Cv) for cylinder & speed
- ✓ Function: single / double / 5-3 center
- ✓ Coil voltage (DC24 / AC220 …)
- ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
- ✓ Single valve or manifold base?
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.8 MPa operating pressure.
- check Match coil voltage to your controller output.
- check Use the manual override to test before powering.
- check Fit silencers or fittings to the exhaust ports.
- check Wiring by qualified personnel per AirTAC docs.
Airtac 4V400 Solenoid Valve 4V430P-15-A FAQ
In the center (de-energised) position, both cylinder ports A and B receive supply pressure simultaneously. This creates a balanced force across the piston, which resists external loads trying to push or pull the rod. It's not a safety lock—if you need guaranteed load holding, add a pilot-operated check valve at the cylinder ports—but it prevents free drifting under a steady opposing force.
With an effective area of 40.0 mm² (Cv 2.35) and a 1/2-inch port, this valve is typically paired with double-acting cylinders in the ~Ø80–125 mm range. The 5/3 body has a slightly smaller flow path than the 5/2 version (48.0 mm²), so factor that in if speed is critical. For smaller cylinders around Ø50–63 mm, a 4V300-series valve is usually a better match.
