Airtac 5A Pneumatic Control Valve 5A11006
2. 3-position pneumatic valve offers three center position functions (exhaust blocked, pressure retained, or exhaust center);
3. 2-position double pilot-operated valve features memory function to retain the last control state;
4. Precision-machined internal bore reduces friction resistance, enabling low actuation pressure and extended service life;
5. Oil-free lubrication design eliminates the need for external lubrication;
6. Modular design allows integration with manifold bases to save installation space;
**Category**: Pneumatic Control Valves | **Brand**: AirTAC | **Series**: 5A --- Note: The translation incorporates industry-specific terminology (e.g., "spool-type," "double pilot-operated," "manifold bases") and structural clarity while retaining the original HTML line breaks. Key technical features like memory function, modularity, and lubrication-free operation are emphasized for professional context.
AirTAC 5A11006 Pneumatic Control Valve Technical Details
- Model: 5A11006 (5A series manual reset valve)
- Valve type: 5/2-way monostable (single solenoid)
- Port configuration: 5 ports (P, A, B, EA, EB), 2 positions
- Port thread size: G1/8 (ISO228 standard)
- Operating pressure range: 0.2–1.0 MPa (29–145 PSI)
- Max flow rate: 750 NL/min (ANR, at 0.5 MPa)
- Actuation type: Electric-pneumatic pilot control
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil power: 1.6W (DC), 2.2VA (AC)
- Response time: ≤30ms (at rated voltage)
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced oil resistance
- Body material: Die-cast aluminum with hard anodized finish
- Ambient temperature: -5℃ to 60℃ (with no condensation)
- Protection class: IP67 (dustproof/water immersion resistant)
- Weight: 320g ±5g (including solenoid coil)
- Dimensions: 58mm(L) × 35mm(W) × 82mm(H) (excluding fittings)
- Port alignment: ISO 5599-1 standard (modular design for manifold mounting)
High-flow pneumatic directional control valve engineered for industrial automation systems requiring rapid cycling and precise air path switching. Features dual exhaust ports (EA/EB) for optimized airflow management and reduced backpressure. The hardened aluminum body withstands vibration in mobile machinery applications. Compatible with ISO mounting systems for easy integration into valve manifolds.
- Plastic injection molding machine clamp controls
- Automated assembly line actuator sequencing
- Textile machinery pneumatic circuits
- Semiconductor handling equipment
- CNC tool changers and fixture clamping
Installation guidelines:
Use locknuts with 12-15 N·m torque for port connections. Maintain 0.5m minimum clearance from high-frequency inverters to prevent electromagnetic interference. Lubricate with ISO VG32 turbine oil if operated in dry environments.
| Property | Property Value |
|---|---|
| sku | 5A11006 |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
