Airtac 5A Pneumatic Control Valve 5A110M5
2. 3-position pneumatic valve offers three center position functions (exhaust blocked, pressure retained, or exhaust center);
3. 2-position double pilot-operated valve features memory function to retain the last control state;
4. Precision-machined internal bore reduces friction resistance, enabling low actuation pressure and extended service life;
5. Oil-free lubrication design eliminates the need for external lubrication;
6. Modular design allows integration with manifold bases to save installation space;
**Category**: Pneumatic Control Valves | **Brand**: AirTAC | **Series**: 5A --- Note: The translation incorporates industry-specific terminology (e.g., "spool-type," "double pilot-operated," "manifold bases") and structural clarity while retaining the original HTML line breaks. Key technical features like memory function, modularity, and lubrication-free operation are emphasized for professional context.
AirTAC 5A110M5 Pneumatic Control Valve Technical Specifications
- Model: 5A110M5 (5A Series)
- Type: 5/2-way single solenoid pilot-operated valve
- Port configuration: 5 ports (P, A, B, EA, EB) / 2 positions
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Max flow rate: 1000 L/min (ANR)
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10%)
- Response time: ≤15ms (at 0.5MPa)
- Seal material: Heat-resistant NBR (Nitrile rubber)
- Temperature range: -5℃ to 80℃ (no freeze)
- Protection rating: IP67 (dust/water resistant)
- Weight: 320g ±5% (without connector)
- Dimensions: 58mm(L) × 34mm(W) × 43mm(H)
- Mounting: ISO 5599-1 standard subplate
- Service life: ≥10 million cycles (at rated conditions)
High-flow directional control valve with metal body construction, designed for industrial automation systems requiring rapid cycling. Features low power consumption (≤2.2W) and integrated surge suppression. The optimized spool design achieves 30% faster response than previous 4V series models. Requires ISO VG32 hydraulic oil lubrication if used in high-frequency applications (>5Hz).
- Plastic injection molding machine clamp control
- Automated assembly line actuators
- Textile machinery cylinder sequencing
- Bottle filling station pneumatic circuits
- CNC tool changer positioning systems
Installation guidelines:1. Use M5 mounting screws with 0.49-0.59N·m torque
2. Maintain ambient humidity below 85% RH
3. Install downstream filter (5μm minimum)
4. For vertical mounting, position solenoid coil upward
5. Allow 15mm clearance for heat dissipation
| Property | Property Value |
|---|---|
| sku | 5A110M5 |
| Position | 5 Ports 2 Position |
| Port Size | M5 |
