Airtac 5A Pneumatic Control Valve 5A12006
2. 3-position pneumatic valve offers three center position functions (exhaust blocked, pressure retained, or exhaust center);
3. 2-position double pilot-operated valve features memory function to retain the last control state;
4. Precision-machined internal bore reduces friction resistance, enabling low actuation pressure and extended service life;
5. Oil-free lubrication design eliminates the need for external lubrication;
6. Modular design allows integration with manifold bases to save installation space;
**Category**: Pneumatic Control Valves | **Brand**: AirTAC | **Series**: 5A --- Note: The translation incorporates industry-specific terminology (e.g., "spool-type," "double pilot-operated," "manifold bases") and structural clarity while retaining the original HTML line breaks. Key technical features like memory function, modularity, and lubrication-free operation are emphasized for professional context.
AirTAC 5A12006 Pneumatic Control Valve Specifications
- Model: 5A12006
- Type: 5-port 2-position (5/2-way) pneumatic actuated valve
- Port size: G1/8 (ISO228 standard)
- Thread type: Parallel (BSPP)
- Operating pressure: 0.2–0.8 MPa (29–116 psi)
- Max flow rate: 750 L/min (Cv=1.3)
- Actuation type: Air pilot operated (requires 0.15–0.7 MPa control pressure)
- Weight: 320g ±5% (including accessories)
- Dimensions: 58mm(L) × 34mm(W) × 82mm(H)
- Body material: Aluminum alloy (anodized surface)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -10℃ to 80℃ (14°F to 176°F)
- Response time: ≤50ms (at 0.5 MPa)
- Port configuration: 2 exhaust ports with silencers
- Protection rating: IP54 (dust protected & water splashed)
High-flow directional control valve featuring dual-pressure pilot operation for reliable switching in industrial environments. The optimized flow path design reduces pressure drop by 15% compared to previous generations. Includes built-in manual override and position indicator for maintenance diagnostics.
- Automated assembly line clamping systems
- Plastic injection molding machine ejectors
- Material handling cylinder control
- Textile machinery pneumatic circuits
- Automotive tire assembly equipment
Installation guidelines:
Mount using M5 screws with vibration-proof washers. Maintain minimum 15mm
clearance below exhaust ports for proper airflow. Lubricate with ISO VG32
grade turbine oil if using non-lubricated air systems.
| Property | Property Value |
|---|---|
| sku | 5A12006 |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
