Airtac 5A Pneumatic Control Valve 5A120M5
2. 3-position pneumatic valve offers three center position functions (exhaust blocked, pressure retained, or exhaust center);
3. 2-position double pilot-operated valve features memory function to retain the last control state;
4. Precision-machined internal bore reduces friction resistance, enabling low actuation pressure and extended service life;
5. Oil-free lubrication design eliminates the need for external lubrication;
6. Modular design allows integration with manifold bases to save installation space;
**Category**: Pneumatic Control Valves | **Brand**: AirTAC | **Series**: 5A --- Note: The translation incorporates industry-specific terminology (e.g., "spool-type," "double pilot-operated," "manifold bases") and structural clarity while retaining the original HTML line breaks. Key technical features like memory function, modularity, and lubrication-free operation are emphasized for professional context.
AirTAC 5A120M5 Pneumatic Control Valve Technical Details
- Model: 5A120M5 (5A Series)
- Valve type: 5/2-way monostable (spring return)
- Port configuration: M5 threaded ports (5 ports total)
- Actuation method: Pneumatic pilot control
- Operating pressure range: 0.2–1.0 MPa
- Max flow rate: 450 NL/min (ANR)
- Response time: ≤50 ms (at 0.5 MPa)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature tolerance: -10℃ to 80℃ (with dry air)
- Weight: 320g ±5g
- Dimensions: 60mm(L) × 35mm(W) × 75mm(H)
- Port thread depth: 10mm engagement
- Hysteresis: ≤0.02 MPa
- Protection class: IP67 (dust/water resistant)
High-flow directional control valve optimized for mid-pressure pneumatic systems. Features zero lubrication design with self-cleaning spool mechanism, ideal for environments with particulate contamination risks. The aluminum alloy body ensures vibration resistance in mobile applications. Requires 5μm filtered compressed air with max 5% relative humidity.
- Clamping fixture sequencing in CNC workstations
- Automatic conveyor diverters in logistics systems
- Plastic injection molding machine actuators
- Textile machinery tension control systems
- Bottle capping machine pneumatic circuits
Installation protocol:
Mount with vibration-damping gaskets in high-shock environments.
For horizontal mounting, ensure exhaust ports face downward to prevent
moisture accumulation. Perform monthly manual cycling during standby periods
exceeding 30 days.
| Property | Property Value |
|---|---|
| sku | 5A120M5 |
| Position | 5 Ports 2 Position |
| Port Size | M5 |
