Airtac 5A Pneumatic Control Valve 5A130PM5
2. 3-position pneumatic valve offers three center position functions (exhaust blocked, pressure retained, or exhaust center);
3. 2-position double pilot-operated valve features memory function to retain the last control state;
4. Precision-machined internal bore reduces friction resistance, enabling low actuation pressure and extended service life;
5. Oil-free lubrication design eliminates the need for external lubrication;
6. Modular design allows integration with manifold bases to save installation space;
**Category**: Pneumatic Control Valves | **Brand**: AirTAC | **Series**: 5A --- Note: The translation incorporates industry-specific terminology (e.g., "spool-type," "double pilot-operated," "manifold bases") and structural clarity while retaining the original HTML line breaks. Key technical features like memory function, modularity, and lubrication-free operation are emphasized for professional context.
AirTAC 5A130PM5 Pneumatic Control Valve Specifications
- Model: 5A130PM5
- Type: 5/2-way single solenoid spring return
- Port size: G1/8 (NPT1/8 optional)
- Operating pressure: 0.2–1.0 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V
- Flow coefficient (Cv): 0.45
- Response time: ≤20ms (at 0.5MPa)
- Weight: 350g ±5% (with solenoid)
- Dimensions: 60mm(L) × 40mm(W) × 80mm(H)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Power consumption: ≤2.5W (DC), ≤3.5VA (AC)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 10mm (minimum engagement)
- Max operating frequency: 5Hz (with 50% duty cycle)
High-flow directional control valve with manual override, featuring brass body construction and low-hysteresis spool design. Optimized for rapid cycling applications with built-in surge suppression. Requires ISO 8573-1:2010 Class 3.4.2 compressed air (max 5μm particle size, 40% relative humidity).
- Automated assembly line actuators
- Packaging machine clamp control
- CNC tool changers
- Material handling systems
- Textile machinery pneumatics
- Food processing equipment (oil-resistant version available)
Installation guidelines:
Mount horizontally with solenoid facing upward. Maintain minimum 15mm
clearance below exhaust ports. Use Loctite 542 thread sealant (not Teflon tape)
for port connections. Lubricate with ISO VG32 turbine oil if air line lubrication
isn't present.
| Property | Property Value |
|---|---|
| sku | 5A130PM5 |
| Position | 5-port 3-position |
| Port Size | M5 |
