Airtac 5A Pneumatic Control Valve 5A22006
2. 3-position pneumatic valve offers three center position functions (exhaust blocked, pressure retained, or exhaust center);
3. 2-position double pilot-operated valve features memory function to retain the last control state;
4. Precision-machined internal bore reduces friction resistance, enabling low actuation pressure and extended service life;
5. Oil-free lubrication design eliminates the need for external lubrication;
6. Modular design allows integration with manifold bases to save installation space;
**Category**: Pneumatic Control Valves | **Brand**: AirTAC | **Series**: 5A --- Note: The translation incorporates industry-specific terminology (e.g., "spool-type," "double pilot-operated," "manifold bases") and structural clarity while retaining the original HTML line breaks. Key technical features like memory function, modularity, and lubrication-free operation are emphasized for professional context.
AirTAC 5A22006 Pneumatic Control Valve Specifications
- Model: 5A22006 (5/2-way monostable)
- Valve type: 5-port 2-position, single solenoid
- Port size: PT1/4 (G1/8 optional)
- Operating pressure range: 0.15–1.0 MPa (21.7–145 psi)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 850 NL/min (ANR, at 0.5 MPa)
- Response time: ≤30 ms (excitation), ≤20 ms (de-excitation)
- Weight: 320g ±5% (including coil)
- Dimensions: 54mm(L) × 45mm(W) × 80mm(H)
- Seal materials: HNBR (main seals), FKM (optional for high-temp)
- Temperature range: -10℃ to 80℃ (extended to 120℃ with FKM seals)
- Protection class: IP67 (coil), IP40 (valve body)
- Port thread depth: 10mm (minimum engagement)
- Hysteresis: ≤0.02 MPa
- Expected lifespan: 50 million cycles (under standard conditions)
High-flow directional control valve with low power consumption design (≤2.2W), featuring dual-color LED status indicator and surge protection circuitry. The aluminum alloy body with hard anodized treatment ensures corrosion resistance in humid environments. Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content). Compatible with vacuum applications when paired with EPDM seals.
- Automated assembly line clamping systems
- Plastic injection molding machine ejectors
- CNC tool changers with rapid cycling
- Beverage filling station actuators
- Semiconductor wafer handling robots
- Textile machinery tension control
Installation guidelines:
Mount in vibration-controlled environments (max 4.9m/s²). Use M5 mounting screws with 0.4-0.6Nm torque.
For horizontal mounting, install exhaust silencers at 15° downward angle to prevent condensate ingress.
Lubricate spool monthly with ISO VG32 turbine oil in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | 5A22006 |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
