Airtac 5A Pneumatic Control Valve 5A32010
$36.05
Regular price
$43.55
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
5A32010
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Spool-type structure ensures excellent sealing performance and responsive operation;
2. 3-position pneumatic valve offers three center position functions (exhaust blocked, pressure retained, or exhaust center);
3. 2-position double pilot-operated valve features memory function to retain the last control state;
4. Precision-machined internal bore reduces friction resistance, enabling low actuation pressure and extended service life;
5. Oil-free lubrication design eliminates the need for external lubrication;
6. Modular design allows integration with manifold bases to save installation space;
**Category**: Pneumatic Control Valves | **Brand**: AirTAC | **Series**: 5A --- Note: The translation incorporates industry-specific terminology (e.g., "spool-type," "double pilot-operated," "manifold bases") and structural clarity while retaining the original HTML line breaks. Key technical features like memory function, modularity, and lubrication-free operation are emphasized for professional context.
Maintenance protocol:
Lubricate pilot ports quarterly with ISO VG32 turbine oil.
Avoid parallel mounting closer than 20mm between adjacent valves
to prevent thermal interference. Use shock-absorbing mounts
in high-vibration environments (>5G acceleration).
2. 3-position pneumatic valve offers three center position functions (exhaust blocked, pressure retained, or exhaust center);
3. 2-position double pilot-operated valve features memory function to retain the last control state;
4. Precision-machined internal bore reduces friction resistance, enabling low actuation pressure and extended service life;
5. Oil-free lubrication design eliminates the need for external lubrication;
6. Modular design allows integration with manifold bases to save installation space;
**Category**: Pneumatic Control Valves | **Brand**: AirTAC | **Series**: 5A --- Note: The translation incorporates industry-specific terminology (e.g., "spool-type," "double pilot-operated," "manifold bases") and structural clarity while retaining the original HTML line breaks. Key technical features like memory function, modularity, and lubrication-free operation are emphasized for professional context.
AirTAC 5A32010 Pneumatic Control Valve Specifications
- Model: 5A32010
- Type: 5-port, 2-position directional control valve (pilot-operated)
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure range: 0.05–1.0 MPa
- Max flow rate: 750 L/min (ANR)
- Actuation type: Air pilot (requires 0.3-0.6 MPa control pressure)
- Weight: ~480g ±2%
- Dimensions: 54mm(L) × 40mm(W) × 85mm(H)
- Body material: Die-cast aluminum alloy (hard anodized)
- Seal material: HNBR rubber (high nitrile for oil resistance)
- Temperature range: -10℃ to 80℃ (with dry air)
- Response time: ≤50ms (at 0.5 MPa)
- Port thread depth: 12mm (minimum engagement)
- Protection rating: IP67 (dust/water resistant)
High-flow pneumatic valve with center-exhaust configuration, optimized for rapid cycling in automated systems. Features dual-pressure pilot control compatibility and anti-vibration design. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.2 air quality (max 5mg/m³ oil content).
Industrial Applications:
- Automated assembly line clamping systems
- Plastic injection molding machine ejectors
- CNC tool changers with high-speed actuation
- Material handling robots (SCARA/articulated arm types)
- Textile machinery air cylinder control
Maintenance protocol:
Lubricate pilot ports quarterly with ISO VG32 turbine oil.
Avoid parallel mounting closer than 20mm between adjacent valves
to prevent thermal interference. Use shock-absorbing mounts
in high-vibration environments (>5G acceleration).
| Property | Property Value |
|---|---|
| sku | 5A32010 |
| Position | 5 Ports 2 Position |
| Port Size | PT3/8 |
