Airtac 5V Solenoid Valve 5V11006E200
2、Terminal-type electrical connection with concentrated internal pilot exhaust, suitable for pollution-free workplaces requiring special environmental conditions;
3、Spool-type structure ensures excellent sealing performance and rapid response; multiple standard voltage ratings available;
4、3-position solenoid valves offer three center function options; double solenoid 2-position valves feature memory function;
5、Precision-machined inner bore minimizes friction resistance, enables low actuation pressure, and extends service life;
6、Compatible with modular valve banks for space-saving installation; integrated manual override facilitates commissioning and maintenance.
Category: Solenoid Valves , Brand: AIRTAC , Series: 5V
AirTAC 5V11006E200 Solenoid Valve Specifications
- Model: 5V11006E200
- Type: 5/2-way single solenoid, spring return
- Port size: PT1/4 (G1/4 thread standard)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage: AC220V 50/60Hz (standard), optional DC versions available
- Weight: 220g ±5g (without connector)
- Dimensions: 55mm(L) × 40mm(W) × 75mm(H)
- Flow coefficient (Cv): 0.45 at 6 bar
- Response time: ≤15ms (open), ≤10ms (close)
- Seal material: NBR (Nitrile Butadiene Rubber)
- Temperature range: -20℃ to 70℃ (non-freezing)
- Power consumption: 2.5W (AC), 2.8W (inrush)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Port alignment: ISO 5599-1 standard
High-flow 5-port pneumatic valve optimized for bidirectional cylinder control in industrial automation. Features dual-pressure capability for vacuum and compressed air systems (0.15–0.8 MPa). The aluminum alloy body with hard anodizing ensures corrosion resistance in humid environments. Includes manual override for system debugging.
- Double-acting pneumatic cylinder control systems
- Industrial robotic arm positioning
- Plastic injection molding machine clamp units
- Textile machinery air circuit switching
- Automated assembly line actuators
- Packaging machine gripper controls
Installation guidelines:
Mount in vibration-free position using M5 mounting screws (max torque 1.2N·m).
Use 5μm filtered air with lubricator (ISO 8573-1:2010 Class 4.4.3).
For horizontal mounting, install exhaust silencers to prevent debris ingress.
| Property | Property Value |
|---|---|
| sku | 5V11006E200 |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | AC24V |
