Airtac 5V Solenoid Valve 5V12006B200
2、Terminal-type electrical connection with concentrated internal pilot exhaust, suitable for pollution-free workplaces requiring special environmental conditions;
3、Spool-type structure ensures excellent sealing performance and rapid response; multiple standard voltage ratings available;
4、3-position solenoid valves offer three center function options; double solenoid 2-position valves feature memory function;
5、Precision-machined inner bore minimizes friction resistance, enables low actuation pressure, and extends service life;
6、Compatible with modular valve banks for space-saving installation; integrated manual override facilitates commissioning and maintenance.
Category: Solenoid Valves , Brand: AIRTAC , Series: 5V
AirTAC 5V12006B200 Solenoid Valve Technical Details
- Model: 5V12006B200 (Full designation: 5V1-20-06-B200)
- Valve type: 5/2-way single solenoid pilot-operated
- Operation mode: Monostable with spring return
- Port size: PT3/8 (G3/8) with ISO 228-1 standard threads
- Effective area: 20mm² (critical for flow capacity calculation)
- Operating pressure range: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage specification: DC24V ±10% (Coil code B200)
- Power consumption: 2.8W (0.12A @24VDC)
- Response time: ≤25ms (both energize/de-energize)
- Body material: Extruded aluminum alloy with hard anodizing
- Seal material: High-grade NBR (Nitrile) - Optional FKM available
- Ambient temperature range: -5℃ to 60℃ (with derating above 40℃)
- Protection class: IP67 (Dustproof & temporary immersion protection)
- Weight: 320g ±5% (including coil and mounting accessories)
- Dimensions: 58mm(L) × 42mm(W) × 82mm(H) (excluding manifold interface)
- Port alignment: 25mm center-to-center spacing (ISO 5599-1 compliant)
High-flow directional control valve engineered for industrial automation systems requiring precise pneumatic sequencing. Features a dual-pressure balanced spool design enabling reliable operation under pressure fluctuations. The copper-free aluminum construction meets ISO 14000 environmental standards. Includes built-in manual override and surge protection circuitry for enhanced maintenance safety.
- Plastic injection molding machine clamp mechanisms
- Automated assembly line cylinder sequencing
- Textile machinery tension control systems
- Food processing pneumatic actuators (NSF compliant version available)
- Semiconductor wafer handling robots
Installation guidelines:
Mount on ISO 5599-1 compliant manifold using M5 mounting screws (3.5Nm torque limit).
Maintain minimum 15mm clearance below valve for heat dissipation.
Use 5μm filtration with automatic drainage for optimal performance.
| Property | Property Value |
|---|---|
| sku | 5V12006B200 |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
