Airtac 5V Solenoid Valve 5V12006F050
2、Terminal-type electrical connection with concentrated internal pilot exhaust, suitable for pollution-free workplaces requiring special environmental conditions;
3、Spool-type structure ensures excellent sealing performance and rapid response; multiple standard voltage ratings available;
4、3-position solenoid valves offer three center function options; double solenoid 2-position valves feature memory function;
5、Precision-machined inner bore minimizes friction resistance, enables low actuation pressure, and extends service life;
6、Compatible with modular valve banks for space-saving installation; integrated manual override facilitates commissioning and maintenance.
Category: Solenoid Valves , Brand: AIRTAC , Series: 5V
AirTAC 5V12006F050 Solenoid Valve Technical Specifications
- Model: 5V12006F050 (Full designation: 5V-12-006-F050)
- Valve type: 5/2-way single solenoid spring return
- Port configuration: 5 ports (P, A, B, R, S) / 2 positions
- Port size: G1/8 (BSPP thread) with ISO standard footprint
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage specification: DC24V ±10% (coil class F)
- Power consumption: 2.1W (0.09A @24VDC)
- Response time: ≤15ms (energize)/≤20ms (de-energize)
- Flow capacity: 650 NL/min (Cv=1.3 at 0.5 MPa)
- Seal material: Heat-resistant NBR (Nitrile rubber)
- Ambient temperature: -5℃ to 60℃ (with anti-condensation measures)
- Fluid temperature: 0℃ to 50℃
- Protection class: IP67 (dustproof/water immersion resistant)
- Weight: 215g ±5g (including coil and connector)
- Dimensions: 55mm(W) × 32mm(H) × 78mm(D)
- Mounting orientation: Any (preferred horizontal)
- Expected service life: 50 million cycles (under rated conditions)
High-flow proportional solenoid valve with precision spool design, featuring brass alloy body with electroless nickel plating for corrosion resistance. The low-hysteresis coil assembly enables stable operation in high-vibration environments. Integrated surge protection diode and LED status indicator. Requires 5μm filtered dry air with oil mist lubrication (ISO 8573-1 class 4.4.3).
- Pneumatic cylinder sequencing in assembly lines
- Vacuum cup control systems for material handling
- Textile machinery tension control modules
- Beverage filling station actuator control
- Semiconductor wafer handling robots
Installation guidelines:
Use M4 mounting screws with 0.49-0.69N·m torque. Maintain ≥20mm clearance
from adjacent components for heat dissipation. Perform manual override
testing monthly using the emergency button. Lubricate spool annually with
ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | 5V12006F050 |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | DC12V |
