Airtac 6HV Manifold Solenoid Valve 6HV0500M10F
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV0500M10F Manifold Solenoid Valve Specifications
- Model: 6HV0500M10F
- Type: 5/2-way monostable (direct-acting manifold type)
- Port size: PT1/2 (G1/2 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 850g ±5% (including manifold base)
- Dimensions: 130mm(L) × 60mm(W) × 50mm(H) (per valve station)
- Flow coefficient (Cv): 2.5
- Seal material: NBR (standard), optional Viton for high temp
- Temperature range: -5℃ to 80℃ (NBR), -5℃ to 150℃ (Viton)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port connection: ISO 228/1 standard (BSPP)
- Manual override: Built-in push-button with lock
- Mounting style: Modular manifold system (up to 20 stations)
High-flow manifold-mounted solenoid valve with ISO standardized dimensions, featuring a dual-coil protection design against voltage spikes. The 6HV series employs a piston-type core structure for reduced friction and improved dust resistance. Requires 5μm filtered lubricated/non-lubricated air (ISO 8573-1 class 3).
- Automated assembly line clamping systems
- Multi-cylinder pneumatic sequencing in packaging machinery
- Plastic injection molding machine ejector controls
- Textile machinery air circuit distribution
- Semiconductor handling equipment vacuum/pressure switching
Installation note:
Manifold base must be torqued to 3.5–4.0 N·m during assembly.
Maintain 20mm clearance below manifold for cable routing.
For multi-valve configurations, install end plates with shock-absorbing pads.
| Property | Property Value |
|---|---|
| sku | 6HV0500M10F |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
