Airtac 6HV Manifold Solenoid Valve 6HV0500M12F
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV0500M12F Modular Solenoid Valve Technical Details
- Full model code: 6HV0500M12F
- Valve type: 5/3-way (closed center) with manual override
- Port configuration: 5 ports (P, A, B, EA, EB)
- Port thread: G1/4 (BSPP) with ISO 228 standard
- Operating pressure range: 0.1–1.0 MPa
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155°C)
- Flow capacity: 850 l/min (Cv=1.3)
- Response time: ≤25ms (energize), ≤35ms (de-energize)
- Seal materials: HNBR main seals with FKM backup rings
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Protection class: IP67 (coil), IP40 (valve body)
- Weight: 520g ±3% (including manifold base)
- Dimensions: 78mm(L) × 44mm(W) × 98mm(H)
- Mounting pattern: ISO 15407-1 compliant
High-flow modular solenoid valve designed for centralized pneumatic systems requiring multi-valve stacking. Features triple-coil protection against overvoltage and thermal overload, with LED status indicators. The aluminum alloy body with hard anodizing ensures corrosion resistance in humid environments. Requires lubricated air (ISO VG32 or equivalent).
- Automated assembly line clamping systems
- Plastic injection molding machine sequences
- Multi-axis pneumatic actuator control
- Semiconductor wafer handling equipment
- Bottle filling station diverters
Installation guidelines:
Maximum stacking limit - 16 valves per manifold. Use copper-free
grease on sealing surfaces. Maintain 20mm clearance below valve
for tubing access. Ground all connected manifolds.
| Property | Property Value |
|---|---|
| sku | 6HV0500M12F |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
