Airtac 6HV Manifold Solenoid Valve 6HV0510M5A050
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV0510M5A050 Modular Solenoid Valve Technical Details
- Model: 6HV0510M5A050
- Type: 5-port/2-position (5/2-way) double solenoid
- Port configuration: G1/8 (ISO228-1 standard)
- Mounting interface: ISO 15407-1 compliant manifold mounting
- Operating pressure: 0.2–1.0 MPa (29–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Maximum flow rate: 750 l/min (ANR) at 0.5 MPa
- Response time: ≤30ms (excitation), ≤50ms (de-excitation)
- Seal material: Heat-resistant NBR (Nitrile) up to 80℃
- Temperature range: -5℃ to 80℃ (non-freezing)
- Coil insulation class: Class F (155℃)
- Protection rating: IP67 (dust/water resistant)
- Weight: 420g ±5% (solenoid body only), 120g per solenoid coil
- Dimensions: 72mm(L) × 32mm(W) × 98mm(H) (manifold mounted height)
- Port spacing: 20mm center-to-center (ISO standard)
- Manual override: Optional paddle-type operator
High-density modular valve designed for multi-station pneumatic systems requiring precise sequential control. Features dual manual override capability and surge-protected coils with LED status indication. The aluminum alloy body with hard anodized treatment ensures corrosion resistance in humid environments. Requires 5μm filtered air with lubricator (ISO 8573-1 class 4-4-3).
- Multi-axis robotic end effector control
- Plastic injection molding machine clamp systems
- Automated assembly line positioning fixtures
- Textile machinery tension control
- Semiconductor wafer handling equipment
Installation guidelines:
Maintain ≤0.5mm manifold surface flatness during mounting. Use torque-controlled tools (1.5N·m max) for manifold screws. Allow ≥15mm clearance below valve for tubing access. Perform monthly blow-down of exhaust ports in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | 6HV0510M5A050 |
| Port Size | M5 |
| Standard Voltage | AC220V |
